Allen Bradley SLC 500 Programmable Controller System Selection Guide

1746-HSCE2 multi-channel high-speed counter: Two sets of ± A, ± B, and ± Z input channels, capable of monitoring up to two orthogonal, differential line drivers or incremental encoders

5. Process control module

1746-BLM blow molding module: 4 independent PID control axes, each channel with a pair of discrete I/O for channel synchronization, with a cycle update time of 100 microseconds

1746-BTM barrel temperature module: 4-zone self-tuning PID heating/cooling temperature control, PID algorithm and tuning auxiliary process algorithm are executed on the module

6. Motion control module

1746-HSTP1 stepper control module: a single axis stepper controller that can provide pulse train output up to 250 kHz

1746-HSRV servo control module: a single axis closed-loop servo controller that executes blocks independently of processor scanning time, with encoder feedback up to 300 kHz

7. Positioning module

1746-QV open-loop speed module: suitable for simple hydraulic applications, can accelerate and decelerate hydraulic cylinders, using up to 7 extension and 7 retraction sections

1746-QS synchronous axis module: 4-axis closed-loop servo positioning control, using internal logic to synchronize multiple axes

8. BASIC language module

1746-BAS/BAS-T: Add data collection and report generation capabilities to SLC systems, with two configurable channels that can connect devices such as printers, operator interface terminals, modems, etc

Network communication options

The SLC 500 family offers a variety of communication modules and devices, supporting different networks including EtherNet/IP, ControlNet, DeviceNet, DH+, DH-485, universal remote I/O, and serial networks.

NetLinx Open Network Architecture

Rockwell Automation's NetLinx open network architecture strategy utilizes open network technology to achieve seamless integration from top to bottom. NetLinx based networks - DeviceNet, ControlNet, and EtherNet/IP - all use the Common Industrial Protocol (CIP), share a common language, and a set of common communication services.

Network Selection Guide

Recommended network communication modules/devices for application requirements

High speed data transmission between information systems/large number of controllers/Internet/intranet connection/program maintenance EtherNet/IP SLC 5/05 processor; 1761-NET-ENI/ENIW Ethernet interface

High speed transmission of time critical data between controllers and I/O devices/deterministic and repeatable data delivery/media redundancy or intrinsic safety options ControlNet 1747-KFC15 message module; 1747-SCNR scanner module; 1747-ACN15/ACNR15 adapter module

Low level devices directly connected to controllers/more diagnostics/reduced wiring and startup time DeviceNet 1747-SDN scanner module; 1761-NET-DNI interface module

Factory level and unit level data sharing/program maintenance DH+SLC 5/04 processor

Unit level data sharing/program maintenance DH-485 1747-KE interface module; 1747-AIC isolated link coupler; 1761-NET-AIC Advanced Interface Converter; 1747-UIC USB Converter

Connection between controller and I/O adapter/distributed control universal remote I/O 1747-SN scanner; 1747-BSN backup scanner; 1747-ASB adapter; 1747-DCM direct communication module

Modems/ASCII device communication serial SLC 5/03/04/05 processors; 1747-KE interface module

Rack and power supply

1. Rack options

The SLC modular rack offers four sizes of slots: 4, 7, 10, and 13, which can be selected according to the requirements of modular hardware components. Each rack requires its own power supply, installed on the left side of the rack. Up to 3 racks can be connected using rack interconnect cables.

Catalog Number Description

1746-A4 4-slot rack

1746-A7 7-slot rack

1746-A10 10 slot rack

1746-A13 13 slot rack

1746-C7/C9/C16 rack interconnect cable

1746-N2 card slot filler

2. Power options

Catalog Number Line Voltage 5V Current Capacity 24V Current Capacity User Current Capacity

1746-P1 85-132/170-265V AC 2 A 0.46 A 0.2 A @ 24V

1746-P2 85-132/170-265V AC 5 A 0.96 A 0.2 A @ 24V

1746-P3 19.2-28.8V DC 3.6 A 0.87 A -

1746-P4 85-132/170-250V AC 10 A 2.88 A 1 A @ 24V

1746-P5 90-146V DC 5 A 0.96 A 0.2 A @ 24V

1746-P6 30-60V DC 5 A 0.96 A 0.2 A @ 24V

1746-P7 10-30V DC isolated 12V input: 2A; 24V input: 3.6A 12V input: 0.46A; 24V input: 0.87A-

Precautions for power selection:

Each rack must have a power supply

Overload may cause power shutdown or premature failure

Consider future system expansion

Calculate the total current demand using a power load worksheet

The power supply can withstand short-term power outages (20ms to 3s, depending on the load)

Programming software and tools

1. RSLogix 500 programming software

The RSLogix 500 ladder diagram programming package provides unparalleled productivity and industry-leading user interface, compatible with programs created using the Rockwell Software DOS programming package.

Main functions:

Flexible editing function: The online editor allows for modifications to the application during runtime; The test editing function can test the modification effect before permanent integration; Drag and drop editing allows for quick movement or copying of instructions

Point and click I/O configuration: allocate modules to slots by clicking or dragging them from the complete list; Advanced configuration of special and simulation modules is easy to access
