HONEYWELL Experion Local Control Network

Parameter specifications

Processor XILINX XC7Z020-1CLG4001

1GB DDR3 SDRAM memory

256MB NOR FLASH flash memory

Input voltage 90-264 VAC, 47-63 Hz

Power consumption 12W (@ 80% efficiency)

Heat dissipation of 9W (@ 80% efficiency)

Working temperature (inside the cabinet) 0 ° C to 70 ° C

Working temperature (outside the cabinet) 0 ° C to 50 ° C

Storage temperature -40 ° C to 80 ° C

Working humidity 10-90% (non condensing)

Storage humidity 5-95% (non condensing)

The highest working altitude is 7500 feet

The maximum length of copper cable is 100 meters

Maximum fiber length of 2 kilometers (requires SFP port support)

Network Type Fault Tolerant Ethernet (FTE)

Data rate 100 Mbit/s (100Base-T)

Corrosive environment G4 (severe)

Compliance certification

ELCN products comply with the following international and regional standards:

CE certification:

Low Voltage Directive 2014/35/EU, compliant with IEC/EN 61010-1, IEC/EN 61010-2-201

EMC Directive 2014/30/EU, compliant with IEC/EN 61326-1

North American certification:

cCSAus：CAN/CSA-C22.2 No.61010-1、IEC/EN 61010-2-201

Korean Certification (KCC):

Compliant with KN 61326-1 electromagnetic compatibility standard

Important note: The above certification applies to the product itself, but the compliance of the final integrated system needs to be jointly evaluated and confirmed by the system owner and the local regulatory authority (AHJ). The equipment must be installed in a cabinet that meets environmental requirements and local regulations.
