Omron FZ5 Vision System Selection and Configuration Guide

来源: | 作者:FAN | 发布时间 :2026-04-27 | 88 次浏览: | 🔊 Click to read aloud ❚❚ ▶ | Share:

Check if the recommended EtherNet/IP cable is being used

Problem 3: Unstable measurement results

Confirm if the lens aperture is fixed and locked

Check if the expansion tube is loose or stacked too much

Use the Precise Calibration processing item to correct lens distortion and keystone distortion

Problem 4: Unable to save image or data

Confirm if the USB drive format is FAT32

Do not insert two USB drives into adjacent USB ports

Check if Image Logging or Data Logging is configured correctly


System Expansion and Accessory Selection

LCD monitor (FZ-M08): 8.4-inch TFT, resolution 1024 × 768, suitable for box type controllers

USB memory: 2GB or 8GB, used for image and data recording

Industrial switch: 3 or 5 ports, supports EtherNet/IP, some models support fault detection

External lighting and controller: FLV/FL series light source, to be used in conjunction with FLV-TCC or FL-TCC series controllers
