ABB 3BSE062980 en H Compact Product Suite

Compact HMI 800 Specificaties en Prestatievoordelen

Specificatie: Windows-gebaseerd, ondersteunt Windows 8.1, Windows 10 2016 LTSB, Windows Server 2012 R2 en Windows Server 2016. Er zijn verschillende versies, zoals 6.0.3.2, 6.0.3 Extended, enz., en elke versie bevat verschillende basissystemen, aantal signalen, HMI-clientconfiguratieopties en signaaltellingen variërend van 50 tot 10000, Er zijn verschillende versies zoals 6.0.3.2, 6.0.3 Extended, enz. Elke versie bevat verschillende configuratieopties voor het basissysteem, aantal signalen, HMI-clients, enz. en het aantal signalen varieert van 50 tot 10.000.


Prestatievoordelen: Gebaseerd op ABB's System 800xA DCS-technologie, met een hoogwaardige vooraf gebouwde, herbruikbare grafische bibliotheek voor eenvoudige bediening. Dankzij de directe aansluiting op een groot aantal OPC-compatibele controllers en ingebouwde regelaars voor aansluiting op grote PLC's is het systeem geschikt voor gebruik in een groot aantal industrieën en kan het worden opgeschaald van een enkel operatorwerkstation tot grootschalige toepassingen.


Panel 800 versie 6.2 Specificaties en prestatievoordelen

Specificaties: Standaard, zwarte en robuuste panelen zijn verkrijgbaar. Standaard paneelformaten variëren van 7“ tot 21,5” met verschillende resoluties, ARM9 (1 GHz) processors en geheugen van 512 MB tot 2,0 GB. Er zijn verschillende goedkeuringen beschikbaar, zoals CE, FCC, KCC, enz., en de bedrijfstemperaturen variëren van -10°C tot +60°C (0°C tot +50°C in sommige gevallen).


Prestatievoordeel: Gebruiksvriendelijk en intuïtief ontwerp, dat een slank en ruimtebesparend ontwerp combineert met een schat aan geavanceerde functies. Stabiele werking in veeleisende omgevingen, zoals zwaar buitengebruik, explosiegevaarlijke omgevingen en cockpits op zee.


Specificaties en prestatievoordelen van AC 800M processorunit

Specificaties: Diverse CPU-modules met klokfrequenties van 24 MHz tot 450 MHz, geheugen van 8 MB tot 256 MB en gedeeltelijke ondersteuning voor CPU-redundantie, met omschakeltijden van slechts 10 ms. Er zijn diverse communicatie-interfaces beschikbaar die PROFIBUS DP, PROFINET IO en andere protocollen met verschillende transmissiesnelheden ondersteunen.


Prestatievoordelen: sterke verwerkingscapaciteit, kan voldoen aan verschillende industriële besturingsvereisten. Ondersteunt verschillende communicatieprotocollen en kan communiceren met gegevens van verschillende apparaten en systemen. Sommige modules ondersteunen een redundantiefunctie, wat de betrouwbaarheid en stabiliteit van het systeem verbetert.


Specificaties en prestatievoordelen van de S800 I/O-module

Specificaties: Bevat verschillende typen modules, zoals digitale in-/uitgang, analoge in-/uitgang, pulstelling en andere modules. Het spanningsbereik van digitale ingangsmodules is van 24 V DC tot 230 V AC, analoge ingangsmodules ondersteunen diverse signaaltypen en nauwkeurigheden en uitgangsmodules hebben verschillende belastingscapaciteiten. Er is een breed scala aan communicatie-interfaces beschikbaar, met ondersteuning voor protocollen zoals PROFIBUS - DPV1.


Voordelen: zeer modulaire en flexibele configuratie, geschikte modules kunnen worden geselecteerd op basis van verschillende toepassingsvereisten. Ondersteunt hot-swapping, online herconfiguratie en redundantie om stilstand te verminderen. Uitgerust met HART straight-through functie, kan communiceren met intelligente apparaten en wordt wereldwijd veel gebruikt in de industrie.


Specificaties en prestatievoordelen van NE800 netwerkcomponenten

Specificaties: Netwerkswitches en routers/firewalls zijn verkrijgbaar in verschillende modellen, zoals NE801, NE802 enzovoort. Er zijn licht beheerde en beheerbare types met verschillende afmetingen, gewicht, beschermingsniveau, werkspanning, nominale stroom en andere parameters. Er zijn verschillende soorten Ethernet-interfaces die snelheden ondersteunen zoals 10/100 Mbit/s, 10/100/1000 Mbit/s, etc. Sommige hebben digitale I/O en console-interfaces.


Prestatievoordelen: Netwerkredundantiefuncties, zoals Fast Network Topology Reconfiguration (FRNT) en Redundant Network Routing Protocol (RNRP), verbeteren de betrouwbaarheid van het netwerk. Sommige producten ondersteunen verschillende Ethernet-interfacesnelheden om te voldoen aan verschillende netwerkvereisten, zijn gecertificeerd door classificatiebureaus en zijn geschikt voor verschillende industriële omgevingen.


Compact HMI 800: is een pc-gebaseerd SCADA-systeem gebaseerd op ABB's System 800xA DCS-technologie, met gebruiksvriendelijke, krachtige grafische weergave, ondersteuning voor een groot aantal Windows-systemen en de mogelijkheid om verbinding te maken met een groot aantal controllers. Omvat producten zoals het basissysteem (met media en licenties), signaaltoevoegingsopties, snapshotrapportage, HMI-client, kantoorwerkruimte en dongle, met functies en configuraties die variëren van versie tot versie.


Panel 800 versie 6.2: is een gebruiksvriendelijk bedieningspaneel dat verkrijgbaar is in standaard, zwarte en robuuste versies met een groot aantal afmetingen en functies. De configuratie wordt uitgevoerd via Panel Builder 800, met het bijbehorende lifecycle managementprogramma, en er is een breed scala aan accessoires beschikbaar, zoals communicatie-interfaces, aansluitkabels, frontbeschermers, enz.
