DEIF AGC 100 series generator set controller

4. Precautions for UL application

The controller is only applicable to generator components that have been certified by UL

Power supply voltage range: 7.5-32.7 V DC

Use 60/75 ° C copper wire

Installed on the flat surface of Type 1 casing

Compliant with NEC (USA) or CEC (Canada) specifications

Installation precautions

1. Safety Warning

Installation work can only be carried out by authorized electrical personnel

It is strictly prohibited to touch the AC measurement input terminal when the equipment is live

Pay attention to electrostatic protection during installation

The factory setting is the average value, and adjustments must be made according to the actual generator set before operation

2. Wiring requirements

All AC measurement circuits must be protected by 2A slow melting fuses

When the relay output drives inductive loads, a noise suppression circuit must be installed

Modbus and CAN buses must use shielded twisted pair cables, with the shielding layer grounded at one end

Bus terminal resistors must be installed according to specifications

3. Check after installation

Confirm that all terminals are securely connected and the torque meets the requirements

Confirm the size of the panel opening and the installation of the buckle in place

Confirm that the power polarity is correct and the voltage range meets the specifications

Confirm that the communication cable wiring is correct and the terminal resistor has been installed

Summary of Application Value

The AGC-100 generator controller provides a cost-effective solution for generator control with its compact design, flexible configuration, and reliable performance. Its main value lies in:

Easy installation: standard panel embedded installation, regular hole size, simple buckle fixation

Clear terminals: The terminal block has clear functional zoning, complete labeling, and is easy to connect

Flexible configuration: supports multiple operating modes (islanding, AMF, power management) to adapt to different application scenarios

Rich interfaces: digital input, multifunctional input, speed input, relay output, communication interfaces are all available

Communication capability: Supports Modbus RTU and CAN J1939, can be connected to the upper computer monitoring system

Scalability: Supports external I/O modules and additional operation panels to meet complex system requirements

Environmental adaptation: Wide working temperature range, IP52/IP65 protection level, suitable for various installation environments
