DEIF AGC 100 series generator set controller

6. Three phase voltage and current input (terminals 28-48)

Main voltage input:

Terminal 28: L1

Terminal 29: N

Terminal 30: L2

Terminal 32: L3

Generator voltage input:

Terminal 33: L1

Terminal 34: N

Terminal 36: L2

Terminal 38: L3

Generator current input:

Terminal 39-40: L1 current (s1/s2)

Terminal 41-42: L2 current (s1/s2)

Terminal 43-44: L3 current (s1/s2)

Circuit breaker relay:

Terminal 45-46: Generator circuit breaker (normally open, 2A @ 30V DC/250V AC)

Terminal 47-48: Main circuit breaker (normally closed, optional M19 for normally open)

7. Communication interface (terminals 49-59)

Modbus RS-485：

Terminal 49: B (-)

Terminal 50: GND

Terminal 51: A (+)

CAN bus (port A):

Terminal 53: CAN-H

Terminal 54: COM

Terminal 55: CAN-L

Optional CAN bus (port B):

Terminals 57-59: Used for AOP-2 additional operation panel or external I/O module (optional H8)

Wiring specifications

1. DC power supply wiring

The auxiliary power input needs to be protected by a 2A slow melting fuse

Power supply voltage range: 6-36 V DC

Suggest using DEIF DCP-2 power supply or equivalent products

2. Digital input wiring

The digital input is a bidirectional optocoupler type, and the typical input circuit is as follows:

Input conduction voltage: 8-36 V DC

Input shutdown voltage:<2 V DC

Typical input impedance: 4.7 k Ω

3. Circuit breaker control

AGC-100 supports three types of circuit breakers:

Circuit breaker type closing output opening output

Pulse type requires

Continuous type required or not

Compact models require

Select the circuit breaker type through PC configuration software and allocate the corresponding relay output in the I/O configuration.

4. Monitoring of charging generator (D+and W terminals)

AGC-100 supports two monitoring methods for charging generators:

Method 1: Connect the D+terminal to terminal 12

Connect the positive terminal of the battery through a REX resistor (12V system: 47 Ω/4W; 24V system: 100 Ω/6W)

When starting, the current flows through REX to assist in exciting the generator

After the generator generates electricity, the voltage at terminal 12 increases, cutting off the excitation current and providing operational feedback

Method 2: Connect the W terminal to the speed input (terminal 18)

Directly monitor the AC frequency of the charging generator

Provide speed signal and operational status feedback

5. AC measurement wiring

Three phase system (AGC 112):

The generator voltage is directly connected to terminals 33-38

The generator current is connected to terminals 39-44 through CT

Suitable for islanded operation mode

Three phase AMF system (AGC 113):

Simultaneously connect the main voltage (terminals 28-32) to the generator voltage

Suitable for automatic mains power fault switching applications

Single phase system:

Connect the voltage to L1 and N

Current connection to L1 CT

Phase separation system:

Voltage connection to L1, L2, and N

Connect current to L1 and L2 CT

6. Power management wiring (AGC 145/146)

AGC 145 (Main Circuit Breaker):

Connect the main voltage, generator voltage, and current

Relay output controls generator circuit breaker and main circuit breaker

AGC 146 (main circuit breaker+bus tie circuit breaker):

In addition to the main circuit breaker, additionally control the bus tie circuit breaker

Suitable for power management between two busbars

Communication interface configuration

1. Modbus RTU

Interface: RS-485, 2-wire system

Supporting protocols: Modbus RTU or ASCII

Maximum bus length: 300 meters

Cable recommendation: Belden 3106A or equivalent (22 AWG shielded twisted pair, shielding coverage ≥ 95%)

Terminal resistor: When the bus length exceeds 30 meters, 120 Ω terminal resistors need to be installed at both ends

2. CAN bus engine communication

Interface: CAN J1939

Maximum bus length: 300 meters

Cable recommendation: Belden 3106A or equivalent (22 AWG shielded twisted pair, shielding coverage ≥ 95%)

Terminal resistor: 120 Ω terminal resistors need to be installed at both ends of the bus

3. External I/O modules

Connected via CAN bus, supports optional H8 external I/O module

Bus length ≤ 300 meters

Use Belden 3106A or equivalent cable

When sharing the bus with AOP-2, the total terminal resistance should be 120 Ω

4. Additional operation panel AOP-2

Connect through CAN port B

Comes with DC-DC converter and 2 x 1 meter RJ12 connection cable

Maximum bus length: 300 meters

Use Belden 3106A or equivalent cable

Summary of Technical Specifications

1. Electrical parameters

Project Parameters

Auxiliary power supply 6-36 V DC (UL/cUL: 7.5-32.7 V DC)

Maximum power consumption of 8W

Measurement voltage range 100-25000 V (primary side)

Measure current range 5-9000 A (primary side, through CT)

Measurement frequency 30-70 Hz

Accuracy Class 1.0

2. Input/output specifications

Project Parameters

Digital input 12/24V DC bidirectional optocoupler, input impedance 4.7k Ω

Multi functional input 4-20mA, digital input Pt1000

Speed input magneto electric, PNP, NPN, W terminals

Relay output (low power) 2A @ 30V DC/V AC

Relay output (high power) 8A @ 30V DC/V AC

Status output 1A @ 24V DC/V AC

3. Environmental conditions

Project Parameters

Working temperature -25 ℃ to+70 ℃

Storage temperature -40 ℃ to+70 ℃

Humidity 95% RH (non condensing)

Protection level IP52 (standard), IP65 (optional L)
