Eaton MP-3000 Motor Protection Relay Guide

Align with the guide rail and push in firmly until the four buckles engage

Removal steps:

If using fiber optic cables, first remove half of the internal chassis and disconnect the fiber optic cables

Simultaneously press the top and bottom quick release buttons

Pull out the relay through the front panel

Important warning: Removing the internal chassis may expose live parts and pose a fatal risk of electric shock. Before touching the internal and external components of the chassis, be sure to disconnect all controls or power sources.

12.6 Application of Disarmament Mode

In drawer style structures, the disarmed mode (ARMED/DISARMED) is particularly useful. This mode prevents the tripping output contact operation, but does not affect the protection display. Allow the insertion of relays without tripping critical motors due to improper settings. If an alarm or trip indication occurs during insertion, the user can check if the protection settings are correct.

Attention: The relay must be set to ARMED mode to protect the equipment. Otherwise, disabling the motor protection may result in serious damage.

Model Supplement

MP3010 fixed housing, 5A CT, no communication

MP3010INCOM fixed housing, 5A CT, with INCOM communication

MP3010MODBUS fixed housing, 5A CT, with Modbus communication

MP3010DEVICEN fixed housing, 5A CT, with DeviceNet communication

MP3110 fixed housing, 1A CT, can communicate through PONI

MP3110INCOM fixed housing, 1A CT, with INCOM communication

MP3110MODBUS fixed housing, 1A CT, with Modbus communication

MP3110DEVICEN fixed housing, 1A CT, with DeviceNet communication

MP3011 drawer style housing, 5A CT, no communication

MP3012 drawer style housing, 5A CT, with INCOM communication

MP3013 drawer style housing, 5A CT, with Modbus communication

MP3014 drawer style housing, 5A CT, with DeviceNet communication

MP3111 drawer style housing, 1A CT, no communication

MP3112 drawer style housing, 1A CT, with INCOM communication

MP3113 drawer style housing, 1A CT, with Modbus communication

MP3114 drawer style housing, 1A CT, with DeviceNet communication

MP3010VPI fixed shell, 5A CT, with INCOM, URTD and FOC

MP3010PPM fixed housing, 5A CT, with Modbus, URTD, and FOC

MP3010VPD fixed housing, 5A CT, with DeviceNet, URTD, and FOC

MP3110VPI fixed shell, 1A CT, with INCOM, URTD, and FOC

MP3110PPM fixed housing, 1A CT, with Modbus, URTD, and FOC

MP3110VPD fixed housing, 1A CT, with DeviceNet, URTD, and FOC

2D78559G01 URTD Universal RTD Module

2D78542G01 IQDCPS DC to AC power converter, 100-150 Vdc

MPFO-1 1-meter prefabricated fiber optic link with connector (for URTD)

MPFO-5 5-meter prefabricated fiber optic link with connector

MPFO-10 10 meter prefabricated fiber optic link with connector

MPFO-25 25 meter prefabricated fiber optic link with connector

MPFO-50 50 meter prefabricated fiber optic link with connector

MPFO-75 75 meter prefabricated fiber optic link with connector

MPFO-76 76 meter prefabricated fiber optic link with connector

MPFO-100 100 meter prefabricated fiber optic link with connector

MPFO-120 120 meter prefabricated fiber optic link with connector

MP3BRACKET PONI mounting bracket

MPML relay mounting board adapter (1/2 inch stud), suitable for GE Multilin 269 opening

MPML-L relay mounting board adapter (1-inch stud), suitable for GE Multilin 269 opening

EPONI Ethernet Communication Module

EPONIFE Ethernet Fiber Optic Communication Module

IPONI INCOM Communication Module

DPONI Data Communication Module

RS-485 PONI Modbus RTU communication module

MD3000 motor/generator differential relay, fixed housing

MD3001 motor/generator differential relay, drawer type housing

MP3011-IC MP-3011 internal chassis, 5A CT, no communication

MP3012-IC MP-3012 internal chassis, 5A CT, with INCOM communication

MP3013-IC MP-3013 internal chassis, 5A CT, with Modbus communication

MP3014-IC MP-3014 internal chassis, 5A CT, with DeviceNet communication

MP3111-IC MP-3111 internal chassis, 1A CT, no communication

MP3112-IC MP-3112 internal chassis, 1A CT, with INCOM communication

MP3113-IC MP-3113 internal chassis, 1A CT, with Modbus communication

MP3114-IC MP-3114 internal chassis, 1A CT, with DeviceNet communication

MP3X11-OC MP-3XXX external chassis, used for non communication or INCOM communication internal chassis

MP3X13-OC MP-3XXX external chassis, used for Modbus communication internal chassis

MP3X14-OC MP-3XXX external chassis, used for DeviceNet communication internal chassis
