Honeywell T901Px1A Inert Gas Pressure & Temperature Transmitter for Liquid Cargo

Installation and connection method

1. Process connection

T901-Px1A adopts standard process connection interface, which is convenient for docking with valves or pipeline systems of various liquid cargo tanks. It has excellent sealing performance and can withstand high pressure and severe vibration environments.

2. Electrical connection

The electrical part adopts a three wire output interface, supporting 0.5 to 2.5 Vdc analog signal output, making it easy to integrate with radar systems, PLCs, or data acquisition systems. The device is powered by 5 Vdc and has low power consumption, making it suitable for use in intrinsic safety systems.

Supporting technical documents

For the convenience of users in installation, debugging, and maintenance, Honeywell Marine provides complete technical documentation for this series of products, including:

Installation Manual (MI5016): Detailed instructions on the mechanical and electrical installation steps of the equipment

Technical Manual (MT5016): Provides complete technical parameters and performance curves

Maintenance Manual (MM5016): Includes daily maintenance, troubleshooting, and component replacement guidance

Summary of Application Scenarios and Advantages

The T901-Px1A series transmitter is widely used in the following scenarios:

Monitoring of liquid cargo tanks in oil tankers and chemical tankers

Inert gas system of liquefied gas transport ships

Remote monitoring system for port storage tank area

Monitoring of hazardous areas on offshore engineering platforms

Its main advantages include:

Integrated design: dual monitoring of pressure and temperature can be achieved in one installation, saving installation space and time

High precision and stability: pressure ± 0.3% FS, temperature meets IEC 751 Class B standard

Intrinsic Safety Certification: Suitable for Zone 0 hazardous areas, with international explosion-proof certification

Modular structure: easy to maintain and clean, improving system availability

Multi probe configuration: supports multi-point temperature monitoring, improves density correction accuracy

Corrosion resistant material: 316L stainless steel and ceramic diaphragm, suitable for marine salt spray environment

Comprehensive documentation support: providing a complete set of installation, technical, and maintenance manuals for easy user operation
