REXRTOH DDS02.1/03.1 Digital AC Servo Drive

DPF05.1-FW (position feedback related firmware)

DSE01.1 (Sum Input Interface)

5. Other/Unclear Classification Modules

DAE01.1

DSSC01.1-FW

DSSC01.3-FW

DSSC02.1

DSSC03.1-FW

4、 Motor and feedback type code

1. Motor series

MDD (Digital Servo Motor)

MKD (Synchronous Servo Motor)

LAR (linear motor with casing)

LAF (Linear Motor)

2. Feedback type (in the motor model suffix)

DSF: Digital servo feedback (corresponding to controller suffix - D)

-L-xxxx

-S-xxxx

-M-xxxx (with multi turn absolute value encoder)

-T-xxxx (with multi turn absolute value encoder)

RSF: Rotary Transformer Feedback (corresponding to controller suffix - R)

-G-xxxx

-K-xxxx (absolute value encoder with pulse generator)

5、 Power unit model

TVM 1.2

TVM 2.1

TVM 2.4

KDV 1.3

KDV 2.2

KDV 2.3

KDV 3.1

KDV 4.1

TVD 1.2

TDA (possibly power related)

KDA3.2 (possibly related to power supply)

TVR3 (possibly power related)

KVR 1 (possibly related to power supply)

6、 Attachment and Cable Kit Model

1. Electrical connection kit

E. - DDS 2 (for DDS02 controller connection)

E. - DDS 3 (for DDS03 controller connection)

S. - DDS 2 (connector kit, selected according to configuration, such as S1-DDS 2, S8-DDS 2, etc., with dozens of variants listed in the document)

2. Mechanical accessories

LE4 220 (fan unit, 220V AC)

LE4 115 (fan unit, 115V AC)

M1-KD (mechanical installation accessories for DDS02.1-A)

SH-FL (DDS02.1-F Liquid Cooling Accessory Kit)

M2-F (DDS02.1-F Liquid Cooling Pipeline Connection Kit)

3. Cable

IKS0391 (service cable for RS232 debugging)

IN 253 (specific motor power cable, color coded)
