ABB UCD208A101 Universal Digital I/O Module

来源: | 作者:FAN | 发布时间 :2025-07-21 | 5 次浏览: | Share:

ABB UCD208A101 Universal Digital I/O Module

Product Overview

ABB UCD208A101 is a universal digital I/O module, which is an important interface component in industrial automation systems, mainly responsible for the input and output conversion of digital signals. It can receive digital signals from on-site devices (such as switch status, sensor trigger signals, etc.) and transmit them to the control system; At the same time, it can also convert the digital instructions issued by the control system into corresponding output signals, driving actuators (such as relays, solenoid valves, etc.) to operate. This module adopts modular design, compact structure, strong compatibility, and can be flexibly integrated into various automation control systems, providing a stable and reliable bridge for signal interaction in industrial sites.


Brand background

ABB, as a leading global power and automation technology company headquartered in Zurich, Switzerland, has a development history of over 130 years. Its business covers multiple key areas such as energy, industry, transportation, and construction, always driven by technological innovation, providing high-quality automation products and solutions to global customers. In the field of industrial automation, ABB's I/O module series products are known for their excellent performance, high reliability, and wide applicability. UCD208A101, as a universal digital I/O module, continues ABB's professional accumulation and strict quality standards in the field of interface technology, and is a trusted component in industrial automation systems.


Specification parameters

Input type: Digital input (dry contact/wet contact)

Output type: Digital output (transistor/relay)

Input points: 8 points

Output points: 8 points

Working voltage: 24V DC

Input current: maximum 5mA per point

Output current: maximum 2A per point (transistor output)

Working temperature range: -25 ℃ to+70 ℃

Storage temperature range: -40 ℃ to+85 ℃

Protection level: IP20 (module itself)

Dimensions (width x height x depth): 45mm x 120mm x 110mm

Weight: Approximately 0.25kg


Core functions

Digital signal input: Supports 8 channels of digital input, compatible with dry and wet contact signals, can accurately detect the switch status, pulse signals, etc. of on-site equipment, and convert them into digital signals recognizable by the control system.

Digital signal output: Provides 8 digital output channels, using transistor or relay output methods, which can drive external actuators according to control instructions to achieve switch control, state switching, and other operations of the equipment.

Signal isolation: Electrical isolation design is adopted between the input and output circuits, effectively suppressing external electromagnetic interference, ensuring the accuracy of signal transmission and the safe operation of the module.

Diagnostic function: It has diagnostic functions such as output circuit short circuit detection and disconnection detection, and can monitor the operation status of the module in real time. When abnormalities occur, it can send out fault signals in a timely manner, which is convenient for maintenance personnel to quickly troubleshoot problems.


Precautions

Wiring specifications: When wiring, it is necessary to strictly distinguish between input and output terminals, ensure that the signal line and power line are connected correctly, and avoid module damage caused by reverse connection or short circuit; For relay output, it is important to ensure that the load current does not exceed the rated value.

Power requirements: The working power supply should be stable at 24V DC, and the fluctuation range should be controlled within the allowable range (usually ± 10%). It is recommended to equip an independent power protection device to prevent voltage surges.

Environmental protection: The module protection level is IP20 and needs to be installed in a closed control cabinet to avoid direct contact with dust and water vapor; The working environment temperature should be controlled between -25 ℃ and+70 ℃ to avoid exceeding the range and affecting performance.

Static protection: When installing, disassembling, or maintaining modules, operators should wear anti-static wristbands to prevent static electricity from penetrating sensitive internal components.

Grounding treatment: The grounding terminal of the module should be reliably grounded, and the grounding resistance should meet the system requirements to enhance anti-interference ability and ensure safety.


Similar model supplement

In ABB's digital I/O module product line, models with similar functionality to UCD208A101 include:

UCD206A101: Both input and output points are 6, with a smaller size, suitable for small automation systems with less demand for I/O points, and relatively low cost.

UCD216A101: With 16 inputs and 16 outputs, it supports higher signal processing capabilities and is suitable for complex industrial scenarios that require a large amount of digital signal interaction, such as centralized signal management for large production lines.
