DEIF XDi series FLEXIBLE DISPLAY INDICATORS

Switch through external buttons connected to NX1 or NX2 modules

Digital input through DX1 digital module (can be set to select modes 1-4)

Controlled by the integrated control system through CANopen or digital control input

Software updates and spare parts management

1. Convenient update mechanism

The XDi has a built-in USB interface at the rear, which allows for easy upgrading of library files or other updates. All standard libraries and customized libraries can be downloaded and uploaded to XDi devices for free. Even if you choose the wrong library file when ordering, there is no need to worry, it can be easily corrected on site.

2. Spare parts strategy

Due to XDi's integration of a virtual indicator library, solutions, and settings, fault issues can be immediately resolved by trained personnel. Reserve spare units of various sizes on board, and the crew can complete the replacement of faulty units within a few minutes, allowing the system to resume operation without waiting for customized instrument spare parts.

Summary of Technical Advantages

The XDi series flexible display indicator has brought revolutionary changes to ship bridge instrument systems, and its core advantages are reflected in:

Space saving: A single indicator replaces multiple traditional instruments, freeing up valuable bridge deck space

Simplified installation: reduces wiring workload, simplifies on-site configuration with installation guides

Flexible configuration: Over 100 pre installed indicator layouts available for on-site selection and adjustment

Mode switching: XDi-N supports up to 4 screens, which can be switched with one click according to the running mode

Network sharing: XDi net realizes multi indicator linkage control and data sharing

Easy maintenance: USB interface can be easily updated, and spare units can be quickly replaced

Customization flexibility: from standard combinations to fully branded three-level customization solutions

Compliance assurance: Configure locking mechanisms to ensure compliance with approval requirements for bridge instrumentation systems

Application scenarios

The XDi series is widely used in the following fields of ships and marine engineering:

Propulsion control and navigation monitoring of merchant ships (cargo ships, container ships, oil tankers)

Directional thruster and rudder angle indication for tugboats and workboats

Bridge instrument integration for luxury yachts and passenger ships

Power positioning system for offshore platforms and special vessels

New instrument requirements for electric and hybrid ships
