Virtual indicator: includes graphic design, which can be a DEIF standard design or a unique design customized according to customer needs. The graphic design complies with relevant ship standards and cannot be modified by users. The single virtual indicator of XDi-N can contain up to 4 screen designs, and users can switch between them.

Virtual indicator settings: Each virtual indicator has one or more settings configuration files that define unique configurations for input, output, control, and optional titles.

Customized solution

DEIF provides three levels of customized services to meet various needs from standard applications to complete branding.

1. Customization level 1: Standard combination library

If users frequently use the same set of standard indicators (such as combinations from azimuth thrusters, tunnel thrusters, and rudder angle libraries), DEIF can compile and pre install these indicators into a customized library for a one-time fee. The indicator content remains unchanged, organized only according to user preferences.

2. Customization level 2: Parameter adjustment

According to system requirements, fine tune standard indicators or default settings parameters to reduce installation site configuration time. The cost of this level is slightly higher than level 1.

3. Customization level 3: Fully customized

Suitable for customers who need unique designs that are consistent with the corporate brand image. DEIF leverages its experience in graphic design and system integration to create a complete custom library for clients. Common customization features include:

Virtual Indicator Design

Product matches customer system with input configuration file

Key frequency band setting

Relay output controlled by critical frequency band

Pop up windows and graphic symbol changes controlled by input values or thresholds

4. Customization of Front Frame Logo

For customers who wish to display their corporate logo on the indicator, DEIF recommends placing the logo on a detachable front frame. Adding a logo to virtual indicator design can take up valuable display space, reducing flexibility and readability.

Installation and configuration process

1. Physical installation

The XDi series adopts a standard panel installation method and is configured and upgraded through the rear USB interface. The expansion module adopts a "quick snap" design, which can be easily installed behind the host:

XDi 96 supports up to 1 expansion module

XDi 144/192 supports up to 2 expansion modules

The types of extension modules include:

NX1: 2 contact inputs for remote button control

NX2: Expansion module with NMEA input/output, supporting XDi net

DX1: Digital input module, used for mode selection and control

2. Installation Wizard and Configuration Lock

After XDi is powered on, it automatically starts the installation wizard and guides users to complete the initial setup:

Definition and locking: Assign CAN node ID, XDi marked as "available but not set" on the CAN bus

Automatic setting: XDi receives configuration from the CAN control system, locks the configuration after completion, and enters normal operation

Manual setting: Follow the wizard instructions to set application parameters, including red scale markings, etc

Final confirmation: After completing the setup, lock the configuration and ensure that the indicator meets the approval and regulatory requirements of the bridge indicator system

For XDi-N models, NMEA settings can be easily accessed in the final stage of the wizard.

3. On site configurable functions

Red Mark Setting: Up to 4 integrated scale red marks can be defined and set on site (if this function has been activated in the library)

Daytime and Nighttime Scale: The standard library includes both daytime and nighttime designs, and dusk design can be added upon request

Front button control: The front button allows for easy screen switching, dimming, and unit conversion. In the XDi-N system, pressing a button can simultaneously control the display of all XDi-N units within the group

XDi net and mode switching function

1. XDi net network

The XDi-N model supports XDi-net through the NX2 module, which is a network protocol based on the CAN bus and has the following characteristics:

Up to 5 indicators can be connected to the same CAN bus, sharing XDi net

NMEA data is shared via CAN bus

The front button can control the dimming level of all indicators within the group

2. Mode switching function

The virtual indicators in the XDi-N library can contain up to 4 screens, each of which can be assigned to modes 1 to 4. By default, Mode 1 corresponds to Screen 1, and so on. But users can assign any screen to any mode number.

Application example: In a system containing 4 XDi indicators, 4 operating modes can be configured:

Port mode

Navigation mode

Homework Mode

Information mode

The captain can switch all four indicators to the corresponding mode of screen display by pressing a button based on the current operational status. Screen allocation can be set through a shortcut menu, and the same screen can be assigned to multiple modes.

Mode switching method:

Use the left button of any indicator to switch
