Moxa EDS-308 series industrial Ethernet switch

Broadcast storm protection: Suppress network broadcast storms and prevent single device failures from causing the entire network to crash;

100% aging test: Full process aging test before leaving the factory to ensure long-term stable operation in industrial scenarios.

Compatible with hazardous areas

Certification: ATEX Zone 2, Class 1 Div. 2, can be used in flammable and explosive environments such as petrochemicals and gas processing to reduce safety risks.

Installation and Accessories

（1） Installation method

DIN rail installation: standard DIN rail buckle, compatible with 35mm standard rail, easy to install densely inside the control cabinet;

Wall mounted installation: Optional wall mounted kit (WK-46) is required, including 2 mounting plates and 8 screws, suitable for scenarios without rails;

Size and weight: 53.6 × 135 × 105mm (width × length × height), weight 790g, compact size, saves installation space.

（2） Recommended accessories

Accessory type, model, specification, and purpose

Power adapter DR-120-24 120W/2.5A, input 88~132VAC/176~264VAC/248~370VDC to provide stable 24VDC power for the switch, compatible with a wide range of input voltages

DR-75-24 75W/3.2A， Input 85~264VAC/120~370VDC medium power supply, suitable for single switch power supply

MDR-60-24 60W/2.5A， Input 85~264VAC/120~370VDC, -20~70 ℃ wide temperature power supply, suitable for harsh temperature environments

Installation kit WK-46 includes 2 mounting plates and 8 screws (46.5 × 66.8 × 1mm) for wall mounted installation of switches, suitable for scenarios without DIN rails

Compliance certification and quality assurance

（1） Core certification

Safety certifications: UL 508 (Industrial Control Equipment), UL 60950-1, CSA C22.2 No. 60950-1 (Information Technology Equipment Safety);

Electromagnetic compatibility (EMC): CISPR 32, FCC Part 15B Class A, EN 55032/24;

Environmental certification: ATEX Zone 2, Class 1 Div. 2 (hazardous areas), IEC 60068 (environmental testing).

（2） Warranty and Reliability

Warranty period: 5-year ultra long warranty, covering the repair of core product faults;

Mean Time Between Failures (MTBF): 255528 hours (according to MIL-HDBK-217F standard), approximately 29 years, with high long-term operational reliability.
