YOKOGAWA CS 3000 TI33Q01B10-01E integrated production control system

Description

CENTUM CS 3000 is an integrated production control system used to manage and control the  operation of plants in a wide variety of industries: petroleum refineries, petrochemical, chemical, pharmaceutical, food and beverages, paper and  pulp, steel and non-ferrous metals, cement, power, gas, water and wastewater. ProSafe-RS can be used as safety instrumented system for these plants.


CENTUM CS 3000 is a key part of most of Yokogawa’s Enterprise Technology Solutions,  and features:

• Open environment for optimizing the whole enterprise,

• Optimal operating environment, hardware upgradeable to the latest technology,

• Flexible, durable system that can be optimized for your plant,

• Minimize total cost of ownership, increase profits,

• Powerful engineering functions,

• Improved Security and Safety for Plants.


Easy Links to Information Systems (ERP, MES systems)

In the past, we used the DCS to optimize the plant on a standalone basis; now there are  requests to optimize the plant operation from an Enterprise Resource Planning (ERP) or  Manufacturing Execution System (MES) viewpoint. The Human Machine Interface (HMI) of CENTUM CS 3000 is general-purpose PCs (IBM PC/AT  compatibles), running Windows 2000 and Windows XP. Windows 2000 and Windows XP have  superb networking functions, and OPC for interfacing with supervisory computers are standard  – so supervisory computers can easily access the process, and you can optimize your company  at the enterprise level. In addition to OPC for communicating between PCs, we can also provide  communication with UNIX machines and the like.


Links to Factory Automation (FA) Systems

In a manufacturing environment, the process control system needs to be synchronized with  subsystems including FA systems and Programmable Logic Controllers (PLCs) which control  packaging, stock management and the like. There are packages for creating optimum systems which integrate CENTUM CS 3000 and many  types of subsystems.


The Operating Environment can incorporate the Latest Technology

Over the last few years, computer technology and networking technology have continued to  progress at an astonishing rate, quickly obsoleting existing HMI hardware. CENTUM CS 3000 uses general-purpose PCs running Windows 2000 and Windows XP as the  HMI, so you can use the latest PC hardware. Windows includes network functions, and future  enhancements to Windows will also result in an enhanced HMI.


Synthesis of DCS and Personal Computers

CENTUM CS 3000 is operated by a mouse, like general-purpose Windows software. However,  the operating environment – control-specific screens, operation and operator keyboard – is  designed to resemble conventional DCSes. Integrating PCs and DCS provides a user-friendly operation environment.
