TOSHIBA DI Series Split Air Conditioner

Product Series Explanation: Efficient Options for Indoor and Outdoor Units

The Toshiba DI series covers a wide range of power to meet the needs of commercial spaces of different scales.

Indoor unit (RAV-SM series): mainly aimed at small and medium-sized commercial spaces. For example, the RAV-SM564 model, as a 2-power indoor unit, has a cooling efficiency of up to 5.0 kW and an energy efficiency of up to 3.21 under cooling conditions. Its size is 256x840x840mm, with moderate weight, making it easy to install or move. For users who require larger cooling capacity, such as the RAV-SM808 (4 horsepower) or RAV-SM1408 (5 horsepower) models, higher cooling efficiency (up to 6.7 kW and 11.2 kW respectively) and larger size are provided. These indoor units place great emphasis on quietness during operation, with noise levels as low as 32dB (A), making them ideal for noise sensitive environments such as conference rooms or open office areas.

Outdoor unit (RAV-SM series): Toshiba offers a powerful series of outdoor units for larger spaces or places that require centralized air supply. Taking the RAV-SM564 outdoor unit as an example, its body height is 550mm, width is 780mm, and depth is 290mm. It supports pipeline connections up to 50 meters long and is equipped with static pressure adjustment function. This model operates on a 50Hz single-phase power supply, with a supply air volume of up to 2130 m ³/h, sufficient to cover vast lobbies or open areas. In terms of energy efficiency, outdoor units also perform well, with an energy efficiency of up to 3.90 under cooling conditions and up to 4.89 under heating conditions. These data demonstrate that Toshiba has not sacrificed energy efficiency while pursuing high performance.

Intelligent control and convenient maintenance: improving user experience and management efficiency

In order to further simplify operations and optimize energy consumption, Toshiba has equipped the DI series with advanced line control systems and various accessories.

Wire controller: Toshiba provides models of wire controllers such as RBC-AMS41E and RBC-AMS51E. These controllers not only support basic timer switch functions (up to 7 days), but also have LCD backlight display and energy-saving options. LCD display allows users to intuitively view current settings, room temperature, and timer status, while energy-saving mode allows the system to automatically switch to low-power operation during non business hours, achieving significant electricity savings. For premium users, remote control is also available, greatly improving the convenience of use.

Accessories and pipeline design: To simplify installation engineering, Toshiba provides a rich ecosystem of accessories. For the concealed ceiling model, extended pipes and smooth streamlined fittings have been designed to support a maximum water outlet lifting of 850mm, and concealed installation is carried out in conjunction with various ceiling structures. For duct type models, flexible duct interface design is provided, supporting complex layouts of polygonal rooms.
