Product Overview

core functionality

For Neptune ®  The series of water meters provide electronic interfaces for water consumption monitoring and support various process controls based on water consumption, which can be integrated with SmartTrol ®  Integrate controllers or third-party instrument devices to build complex measurement and monitoring systems.

Product Model and Classification

Divided by signal type

Digital Pulse

Basic model: 3-terminal design, outputting electrical pulses corresponding to water flow rate, requiring 12-24VDC power supply, suitable for scenarios that only require digital signals.

E2/E3 models: 5-terminal design, retaining basic features, new high-resolution output terminal and counting direction terminal, supporting high-speed bidirectional counter connection, also requiring 12-24VDC power supply, suitable for high-resolution digital signal demand scenarios.

Adaptation types: divided into two categories: Disc specific and Turbine specific, which can adapt to all Neptune disc or turbine watches.

Simulate 4-20mA type

5-terminal design, with digital pulse type basic functions, providing additional 4-20mA analog signal output proportional to water flow rate, requiring 24VDC power supply, suitable for scenarios that require both analog and digital signals.

Adaptation requirements: Strictly match the size and type of the water meter, confirm the compatible model when purchasing, and contact the manufacturer for technical support if necessary.

Special Model Description

The TRICON/E3 transmitter is not submersible and is not recommended for pit installation scenarios.

The T-8 disc gauge has been discontinued. Currently, all TRICON/E transmitters compatible with disc gauges are T-10 type. When compatible with T-8 gauges, it may not be possible to achieve a 20mA output level. The relevant values are only for calibration reference.

Key technical parameters

environmental conditions

Working temperature: 0 ° C~70 ° C (32 ° F~158 ° F)

Storage temperature: -40 ° C~85 ° C (-40 ° F~185 ° F)

Working humidity: 0~95% RH, no condensation

Electrical specifications (classified by model)

Pulse output (working temperature 0-70 ° C)

Low level output voltage (Vol): typical value 0.4V

High level output voltage (Voh): minimum value 8.5V, maximum value 12V, typical value is the power supply voltage minus 1.0V

Low level output current (Iol): typical value -10mA

High level output current (Ioh): typical value+10mA

Output rise time (tr l-h): maximum value 2 μ S (RL=2.4K Ω, CL=50pF）

Output decay time (tf h-l): maximum value 2 μ S (RL=2.4K Ω, CL=50pF）

4-20mA model (working temperature 0-50 ° C)

Power supply voltage (VCC): 22.5~26.5VDC

Power supply current (IS): 20~80mA

Loop resistance (RL): 0~600 Ω

Range accuracy (Gain): maximum 0.5% FS

Zero offset accuracy (Zero): maximum 0.2% FS

The digital pulse output parameters are consistent with the pulse output model

HF and UP/DN models (working temperature 0-70 ° C)

Power supply voltage (VCC): 11.5~26.5VDC

Power supply current (IS): 20~50mA

Low level output voltage (Vol): maximum value 0V

High level output voltage (Voh): typical value 24V, maximum value 26.5V

Low level output current (Iol): minimum value -1.0A

High level output current (Ioh): typical value 0.04A, maximum value 1.0W/Voh

Output rise/fall time: maximum value 2 μ S (RL=2.4K Ω, CL=50pF）

Absolute limit values for all models

Working temperature: 0~85 ° C

Storage temperature: -40~85 ° C

Power supply voltage: -30~30V

Pulse output load resistance: minimum 1200K Ω

Pulse output current: maximum 10mA

Note: Exceeding the above limit values may result in equipment damage

Performance data (classified by water meter type)

T-10 Disk Watch

Water meter size (inches) Maximum flow rate (gpm) Continuous maximum flow rate (gpm) Minimum flow rate (gpm) Number of pulses per gallon Maximum flow rate Pulse output (Hz) 4-20mA Output flow range (gpm)

⅝ 20 10 ¼ 578.10 192.70 0–20

¾ 30 15 ½ 322.60 161.30 0–30

1 50 25 ¾ 150.80 125.67 0–50

1½ 100 50 1½ 67.57 112.62 0–100

2 160 80 2 37.30 100.00 0–160

Note: The high-resolution output of TRICON/E2 requires multiplying the number of pulses per gallon and the maximum flow pulse output value by 36, and E3 requires multiplying by 40

T-8 Disc Watch (discontinued)

Water meter size (inches) Maximum flow rate (gpm) Continuous maximum flow rate (gpm) Minimum flow rate (gpm) Number of pulses per gallon Maximum flow rate Pulse output (Hz) 4-20mA Output flow range (gpm)

⅝ 20 10 ¼ 473.60 157.87 0–24.41

¾ 30 15 ½ 329.14 164.57 0–29.40

1 50 25 ¾ 126.55 105.46 0–59.58

1½ 100 50 1½ 47.86 79.77 0–141.18

2 160 80 2 25.60 68.27 0–234.37

Note: The high-resolution output coefficient is the same as the T-10 table; When the T-10 transmitter is adapted to the T-8 meter, the theoretical flow rate corresponding to the 20mA output is greater than the maximum allowable flow rate of the water meter, which cannot be achieved in actual operation

Trident ®  Turbine gauge (TT)

Water meter size (inches) Continuous maximum flow rate (gpm) Minimum flow rate (gpm) Pulses per gallon Maximum flow rate Pulse output (Hz) 4-20mA Output flow range (gpm)
