Overview

The Hitachi EH-150 series is a compact and powerful modular programmable logic controller (PLC) designed to meet a wide range of industrial automation needs. This series of controllers not only inherits the software assets of Hitachi H-series PLCs, ensuring program portability, but also significantly expands performance and functionality, integrating 32-bit RISC processors to achieve high-speed and precise control.

The design concept of EH-150 emphasizes achieving maximum efficiency in a limited space, and its standard I/O module integrates pluggable terminal blocks and LED status indicator lights, greatly facilitating wiring and on-site diagnosis. The system supports DIN rail installation, with a sturdy structure that adapts to harsh industrial environments. As an important member of the H-series family, EH-150 not only provides a seamless upgrade path for existing H-series users, but also builds a highly scalable control system platform for new users.

System architecture and core features

2.1 Modular Hardware Structure

The EH-150 adopts a typical modular structure, and the core components of the system include:

CPU module: The "brain" of the system, responsible for executing user programs, performing logical operations, and I/O control. Different models, such as EH-CPU104A and the high-performance EH-CPU548, offer program capacities ranging from 3.5k steps to 48.5k steps, as well as basic instruction execution speeds from 1.0 μ s to 0.1 μ s, to adapt to application scenarios of different complexities. High performance CPUs (such as EH-CPU516/548) support up to 4 expansion boards and up to 3520 I/O points.

Power module: provides stable operating voltage for the system. Supports AC 100-240V wide range input (EH-PSA) or DC 24V input (EH-PSD).

I/O modules: including digital input/output (such as EH-XD series, EH-YT series), analog input/output (such as EH-AX series, EH-AY series), temperature detection (EH-PT4), high-speed counting (EH-CU), positioning control (EH-POS) and other modules, to meet the requirements of on-site signal acquisition and driving.

Base board and expansion cable: The base board is used to install CPUs, power supplies, and I/O modules, while the expansion board can greatly expand the system's I/O capacity through I/O controllers and dedicated cables. For example, using EH-CPU548 in conjunction with EH-BS11A 11 slot substrate can achieve a massive system configuration of up to 5 substrates and 55 slots.

2.2 Advanced Communication Capability

The EH-150 performs well in communication and provides a high degree of flexibility:

Dual standard communication ports: The CPU module comes standard with two communication serial ports (Port 1 and Port 2). Port 1 can be configured as a universal port through DIP switches and special internal outputs, supporting RS-232C, RS-422/RS-485 interfaces, and even built-in terminal resistors, making it easy to build a 1: N small data link system.

Built in modem interface: Specific CPU models (such as EH-CPU308 (A) and above) support connecting a modem on port 1 to monitor and maintain remote systems through the public telephone network.

Network module support: By extending the communication module, EH-150 can access various industrial networks, including Ethernet (EH-ETH), DeviceNet (EH-RMD/EH-IOCD), and PROFIBUS-DP (EH-RMP/EH-IOCP), enabling seamless integration into complex factory network architectures.

2.3 Data Security and Reliability

Battery free program maintenance: User programs are stored in the built-in FLASH memory of the CPU module, and even if the battery is depleted or not installed, the program will not be lost, greatly improving the reliability of the system.

Real time clock and logging function: Most CPU models (except EH-CPU104 (A)) have a built-in real-time clock that can timestamp events. Combined with EH-MEMD memory board, the system supports data logging function, which can record the historical data of designated data areas for process analysis and fault tracing.

Rich self diagnostic functions: The CPU module continuously performs self diagnostic tests, including memory checks, I/O configuration verification, program syntax checks, and watchdog timer monitoring. When an error is detected, an alarm will be triggered through the ERR LED indicator and a detailed error code from the special internal output (WRF000).

Powerful instruction system

The EH-150 has a rich instruction system, based on the H-series ladder diagram/instruction language, providing users with great flexibility in programming. Instructions are mainly divided into the following categories:

3.1 Basic Instructions

This includes basic touch commands (LD, AND, OR), output commands (OUT, SET, RES), and edge detection commands (DIF, DFN). These are the foundations of any ladder diagram program.

3.2 Timer and Counter

The system provides various timers and counters:

Timer: including traditional turn-on delay timer (TD) and newly extended TM timer. The number of TM timers is as high as 2048, and each timer can independently select a 0.01s, 0.1s, or 1s time base. The accumulator value range is from 0 to 65535, greatly enhancing the flexibility of timing tasks.
