In the fields of modern industrial manufacturing, packaging sampling, identification production, and composite material processing, the performance of precision cutting equipment directly determines production efficiency and product quality. The C-series digital cutting platform launched by Kongsberg Precision Cutting Systems has become a benchmark in the global packaging, display, labeling, and industrial composite material processing industries due to its modular design, rich tool configuration, and intelligent iPC cutting console. This article is based on the official user manual and comprehensively analyzes the safety specifications, operating procedures, tool systems, automation options, and maintenance of the C-series cutting system, providing a detailed technical guide for operators and technical managers.

Chapter 1: System Overview and Security Design

Konsberg C series cutting system is a highly integrated digital processing platform, which is suitable for cutting, indentation, milling and drawing operations of corrugated cardboard, folding carton, foam board, plastic corrugated board, honeycomb board, composite materials, flexible materials and other media. The system consists of a cutting table, a cross beam, a Y-axis carriage, a tool head, a main power unit (MPU), an operation station, and optional automation accessories.

Safety first: multi-level protection system

The C-series design strictly follows international safety standards, but operators must fully understand and comply with safety regulations to avoid injury risks.

Critical safety equipment

Emergency stop button: distributed on both sides of the operation station and crossbeam, press it to immediately stop all movements.

DynaGuard security system: using a photoelectric sensing beam, the system will stop urgently when the operator's body or foreign objects enter the dangerous area.

Yellow/black warning tape: Identify hazardous areas and only allow operators to enter.

Y carriage warning light: Constant light indicates servo power on, flashing indicates safety system triggered.

Milling spindle warning light: Red flashing indicates that the spindle is starting or stopping, and must wait for complete stillness before touching.

Residual risk perception

Despite the design of multiple protections, there are still residual risks such as:

Lower end of crossbeam: Without protection, it is strictly prohibited to stay or work during operation.

The top of the Y carriage: There is no protection around it, and it is strictly prohibited to approach during operation.

Internal cable drag chain: There is a risk of compression, and entry is prohibited during operation.

Knife injury: All blades and milling cutters are extremely sharp, and cut resistant gloves must be worn when replacing them.

Milling spindle inertia: The maximum downtime can reach 4 seconds, and it must be visually confirmed to be completely stationary before touching.

Personal protective equipment

Kongsberg strongly recommends that operators wear:

Tight fitting workwear: Avoid getting tangled by moving parts.

Cut resistant gloves: protect hands when handling materials and knives.

Goggles: Prevent flying debris and tool breakage during milling operations.

Ear cushions: During long-term work, the typical noise level is 78.5-83.5 dBA, with a maximum of 98.5 dBA.

Chapter 2: System Composition and Basic Operations

Main component naming

Cutting table: a vacuum adsorption platform for carrying materials.

Traverse: Move along the X-axis direction.

Y Carriage: Move left and right along the crossbeam to carry the tool head.

Tool head: There are two tool positions, P1 and P2, which can accommodate various tools.

Main power unit (MPU): including main switch and fuse.

Operation station: equipped with a rotating display, USB interface, and operation panel.

Operation panel functions

Servo power button: Turn on/off the servo power and reset the safety system at the same time.

Start button: Start executing the machining operation.

Pause/Safety Reset Button: Pause the task or reset the safety system.

Vacuum switch: Turn on/off the material adsorption vacuum.

Blowing function: forms an air cushion on the tabletop, making it easy for materials to move.

Manual belt clamping: Use a foot pedal to manually move the conveyor belt.

Panel reference point setting: Set the current position of the laser as the reference point.

Zeroing function: Move the tool head to the selected reference point.

Tool lowering: Manually lower the selected tool.

Joystick: Manually move the tool head, and the angle of the joystick determines the speed; Press the joystick for 2 seconds to switch to incremental jog mode.

Power on/off process

Power on: Start the front-end PC → Turn on the desktop main power → Double click the iPC icon → Press servo power/safety reset → Press start to complete zeroing.

Shutdown: Exit iPC → Turn off main power → Turn off PC.

Chapter 3: Homework Preparation and Execution

Create and set up assignments

Create homework: Select a file from the homework list.

Layer settings: Assign layers and tools to different processing contents (cutting, indentation, milling).
