Overview

This document is the general specification sheet for Yokogawa Electric's FIO (Fieldnetwork I/O) system (document number: GS 33K50F10-50E), updated to version 8 in September 2014. Its core purpose is to guide the deployment, module selection, and installation of the system in CENTUM VP (Vnet/IP). As a field I/O solution, the FIO system is connected to the field control unit (FCU) through ESB/optical ESB/ER bus, supporting dual redundancy configuration and adapting to the signal acquisition and control needs of various industrial scenarios. The module types cover all categories such as analog, digital, and communication, and meet multiple international safety and EMC standards.

System architecture and bus specifications

（1） Overall architecture

The FIO system is based on the core architecture of "FCU+node unit+bus". The node unit includes a power module, a bus interface module, and an I/O module, which can be extended in a chain/star configuration through an optical ESB bus relay unit (ANT10U). It supports dual redundancy configuration (power supply, bus, I/O module) to ensure high availability of the system.

（2） Three major bus core specifications

Bus type suitable for FCU transmission rate, transmission distance support, node unit topology structure

ESB bus AFV30 /AFV40 /AFV10  128 Mbps ≤ 10m ANB10  bus type

Optical ESB bus AFV30 /AFV40  128 Mbps up to 50km (ANT411 relay) ANB11 , ANT10U chain/star type

ER bus AFV10  10 Mbps YCB141: ≤ 185m; Hybrid cables must meet the formula limit ANR10  bus type

Core Component Details

（1） Control Unit (FCU)

Model series type installation method adaptation bus

AFV30  (S/D) standard/dual redundant 19 inch rack mounted ESB/optical ESB bus

AFV40  (S/D) standard/dual redundant with cabinet ESB/optical ESB bus

AFV10  (S/D) standard/dual redundant 19 inch rack mounted ESB/ER bus

（2） Node unit and relay unit

Unit type, model series, functional redundancy support

ESB node unit ANB10  (S/D) connects to the ESB bus and installs I/O module single/dual redundancy

Optical ESB node unit ANB11  (S/D) is connected to the optical ESB bus with optical relay single/dual redundancy

ER node unit ANR10  (S/D) is connected to the ER bus and installed with I/O module single/dual redundancy

Optical ESB relay unit ANT10U optical ESB bus extension, supporting chain/star type-

（3） I/O module classification and core parameters

The FIO system I/O modules cover 6 major categories, with the following key parameters (representative models):

Module type, representative model, number of channels, signal type, isolation characteristics, power consumption (5V DC/24V DC)

Analog input AAI141 16 4~20 mA non isolated 310 mA/450 mA

Analog output AAI543 16 4~20 mA isolated 230 mA/540 mA

TC/mV input AAT141 16 TC (J/K/E, etc.), -100~150 mV isolation 450 mA/-

Digital input ADV151 32 24 V DC isolated 500 mA/-

Digital output ADV551 32 24 V DC isolated 700 mA/-

Communication module ALF111 4-port Foundation Fieldbus (31.25 kbps) -500 mA/-

Turbomachinery module AGP813 26 high-speed protection signal isolation 900 mA/-

Built in isolation barrier module ASI133 8 4~20 mA isolation 150 mA/450 mA

Environmental and power specifications

（1） Environmental requirements

Environmental parameters, working status, transportation/storage status

Temperature range of 0-60 ℃ (standard); -20~70 ℃ (wide temperature option) -40~85 ℃ (wide temperature option)

Humidity 5-95% RH, no condensation 5-95% RH, no condensation

Temperature change rate ± 10 ℃/h ± 20 ℃/h

Vibration 1-14Hz: displacement ≤ 0.25mm; 14-100Hz: acceleration ≤ 2.0 m/s ²-

Dust ≤ 0.3 mg/m ³-

Altitude ≤ 2000 meters-

（2） Power specifications

Communication input: 100-120V AC (± 10%) or 220-240V AC (± 10%), frequency 50/60Hz (± 3Hz), distortion ≤ 10%

DC input: 24V DC (± 10%), ripple rate ≤ 1% p-p

Instantaneous power outage tolerance: ≤ 20ms (under rated AC voltage)

Grounding requirements: independent grounding, grounding resistance ≤ 100 Ω

Connection method and terminal configuration

（1） Signal connection method

The module supports three connection methods to adapt to different on-site requirements:

Pressure clamping terminal: directly connected to on-site equipment, supporting single/double redundant terminal blocks

Specialized cables (such as YCB301, YCB141): connecting modules to terminal boards

MIL connector cable: No terminal block required for direct connection, equipped with anti loosening sheath (ACCC01)

（2） Example of Terminal and Module Combination

Module type pressure clamping terminal dedicated cable MIL connector cable

Analog I/O (AAI141/AAI543) Support Support Support

Digital I/O (ADV151/ADV551) supports partial support

Communication module (ALF111/ALP111) partially supported but not supported

Built in isolation barrier module (ASI133/ASD143) is not supported

Installation restrictions and precautions

（1） Power capacity limitation

Module installation must comply with the "factor summation" rule to avoid power overload:

Installation location application scenario factor summation threshold

ANB10 /ANB11 /ANR10  Non hazardous area ≤ 100
