Attention: If using VT input for power measurement at the same time, a secondary voltage independent of the motor direction must be provided to the voltage transformer (PT) (i.e. PT connected to the motor input terminal, not downstream of the contactor after forward/reverse switching), otherwise the voltage phase will be incorrect during reverse rotation.

Appendix: MM2 Setpoint Quick Reference (excerpt)

The following are the default values and ranges of the most commonly used parameters in debugging (see Appendix A of the manual for a complete list):

Parameter Path Parameter Name Default Value Range

S1: CONFIGURATION Phase CT Primary Amps 100 A 1～1000 A

S1: CONFIGURATION Ground Fault CT Input 50:0.025 CBCT 50:0.025 / 5A SEC CBCT / 5A RESIDUAL

S1: CONFIGURATION VT Primary Voltage OFF 110-600 V or OFF

S1: CONFIGURATION Serial Comms Failure Trip OFF for 5-25 seconds or OFF

S2: Protection Full Load Current 100 A 5-1000 A (or 0.5-100.0 A)

S2: PROTECTION Overload Curve Number 4 1～8, CLASS10/15/20/30

S2: PROTECTION Hot/Cold Curve Ratio 75% 20～100%

S2: Protection Ground Fault Trip Level OFF (must be manually enabled) 3-100% CT or OFF

S2: Protection Stalled Rotor Trip Level 4.50 x FLC 1.15-4.50 x FLC or OFF

S3: PROCESS Interlock Input x Function NOT USED More than 35 functions to choose from

S4: CONTROL Undervoltage Restart ENABLE ENABLE / DISABLE

S5: MONITORING Motor Greasing Interval OFF hours 100-50000 hours or OFF
