UNIOP EK-12 Operator Panel (model 6ZA952-7)

Overview

The UNIOP EK-12 (model 6ZA952-7) is a robust operator panel designed for applications requiring simple text-based operator interface. It features a 2-line by 20-character backlit LCD, providing clear alphanumeric information. Twelve programmable function keys allow for flexible machine control and menu navigation. This panel is part of the EK series, known for its reliability and ease of use in industrial environments.

Key Features

• 2-line x 20-character LCD with LED backlight (green)

• 12 programmable function keys with tactile feedback

• Isolated RS232 and RS485 communication ports

• IP65 front panel for protection against dust and water jets

• Compact dimensions: 160 x 100 x 40 mm

• Wide power supply range: 12-24 VDC

• Simple configuration via UNIOP programming software

Technical Specifications

• Display: 2 lines, 20 characters, 5x8 dot matrix, STN LCD

• Keys: 12 membrane keys, 1 million operations

• Processor: 16-bit microcontroller

• Memory: 512 KB Flash for application storage

• Serial Ports: 1 x RS232, 1 x RS485 (isolated, up to 115.2 kbps)

• Power Consumption: < 4 W

• Operating Temperature: 0°C to +50°C

• Dimensions: 160 x 100 x 40 mm

• Weight: 0.5 kg

Protocol Support

The EK-12 supports a variety of PLC protocols including Siemens S5, Allen-Bradley DF1, Modicon Modbus RTU, and Omron Host Link. Custom ASCII protocols can be implemented using the configuration tool. The isolated serial ports ensure reliable communication in electrically noisy industrial environments.

Applications

Ideal for small machines, conveyor systems, packaging equipment, and as a low-cost operator interface for retrofitting older machinery. Its robust construction and sealed front make it suitable for harsh environments such as food processing or light industrial applications.

Certifications

CE and UL certified. Designed to meet industrial immunity and emission standards. IP65 front panel protection.
