UNIOP ETOP 05-0045 5.7" Touch HMI

Overview

The UNIOP ETOP 05-0045 is a popular 5.7-inch graphical HMI from the eTOP family, designed for a wide range of industrial automation applications. It features a 5.7-inch TFT color display with 640x480 pixel resolution (VGA) and 65,536 colors, delivering sharp and vibrant visuals. The analog resistive touch screen ensures reliable operation even with gloves or in wet environments.

Key Features

• 5.7" TFT LCD, 640 x 480 pixels (VGA), 65k colors

• Resistive touch screen with scratch-resistant surface

• 10/100 Ethernet port with web server and OPC UA support

• USB host (type A) for data logging and peripheral connection

• USB device (mini-B) for programming

• RS232 and RS485 isolated serial ports

• IP65 front panel for protection against dust and water

• Wide operating temperature: -10°C to +55°C

Technical Specifications

• Processor: 400 MHz ARM Cortex-A8

• Memory: 128 MB RAM, 256 MB Flash

• Display Brightness: 350 cd/m²

• Ethernet: 10/100 Base-T, RJ45

• Serial: 1 x RS232, 1 x RS485 (isolated, 2.5 kV)

• USB: 1 host type A (2.0), 1 device mini-B

• Power: 24 VDC ±20%, 8 W max

• Dimensions: 200 x 150 x 45 mm

• Weight: 0.9 kg

Software and Protocol Support

The ETOP 05-0045 is programmable with UNIOP's advanced design studio, which supports vector graphics, multi-language projects, alarms, and recipes. It includes built-in drivers for all major PLC brands such as Siemens, Allen-Bradley, Modicon, Omron, and Mitsubishi. The integrated web server enables remote diagnostics and control via any web browser.

Applications

Ideal for small to medium-sized machines, including packaging equipment, textile machinery, HVAC systems, and medical devices. Its 5.7-inch size offers a good balance between display area and panel footprint.

Certifications

CE, UL, and FCC listed. Designed to meet industrial standards for immunity and emissions (IEC 61000-6-2, IEC 61000-6-4).
