Product positioning and core identification

1769-L32E is a compact programmable automation controller (PAC) from the Allen Bradley CompactLogix L32E series, designed specifically for small and medium-sized industrial automation scenarios. Its core function is to integrate logic control, motion control, and process control capabilities to achieve centralized management of discrete devices (such as machine tools, assembly lines) or small production lines. It is also compatible with Allen Bradley 1769 series I/O modules, balancing flexibility and cost-effectiveness.

Core hardware specifications

1. Processor and Storage

Category specific parameters

Processor performance: 32-bit processor, supports parallel task processing, with a logic control instruction execution speed of 0.68 ms/k ladder diagram instructions, meeting the real-time requirements of small and medium-sized systems

Memory Configuration - Program Memory: 512 KB (used to store user programs and system configurations)

-Data memory: 1 MB (used for caching process data, variables, and status information)

Storage expansion supports external microSD card expansion (available separately) for program backup, data log storage, or firmware upgrade, enhancing data storage flexibility

2. Physical dimensions and installation

Dimensions: Width 44.5 mm x Height 118 mm x Depth 86 mm (Compact design, compatible with 1769 series standard rack);

Installation method: Supports DIN rail installation (compliant with EN 50022 standard) or panel installation, and needs to be paired with 1769 series racks (such as 1769-A10, 1769-A13, etc.). A single rack can expand up to 16 I/O modules;

Weight: Approximately 0.3 kg, lightweight design reduces the load-bearing pressure of the rack.

3. Power supply and power consumption

Power supply voltage: 24 V DC (industrial standard DC power supply, compatible with control cabinet centralized power supply);

Rated current: 0.5 A (without expansion module), after expanding the I/O module, the power supply capacity needs to be increased according to the total power consumption;

Power protection: Supports overcurrent protection and reverse polarity protection to prevent equipment damage caused by abnormal power supply;

Power consumption: Typical power consumption of 12 W (without expansion), low-power design, suitable for energy-saving automation systems.

Communication interface and protocol compatibility

1. Built in communication interface

Number and specifications of interface types

Ethernet interface with 1 RJ45 port, supporting 10/100 Mbps adaptive speed, with Link/Activity indicator light, used to connect to upper computer, HMI or other controllers

Internal backplane interface: 1 1769 series backplane interface, supporting high-speed communication with I/O modules of the same series (such as digital, analog, and special modules), with a backplane data transmission rate of 16 Mbps

One USB 2.0 port (Type B) is used to connect to a programming computer, enabling program download, upload, and online monitoring, simplifying the debugging process

2. Support communication protocols

Industrial Ethernet protocols: EtherNet/IP (core protocol, supports CIP communication, enables data exchange between controllers and real-time I/O control), Modbus/TCP (compatible with third-party devices such as instruments and frequency converters);

Internal communication protocols: CIP Motion (for motion control, supporting single axis or multi axis synchronous control), CIP Sync (IEEE 1588 precise time synchronization, improving multi device collaboration accuracy);

Programming and Configuration Protocol: RSLinx Communication Driver (adapted to Rockwell RSLinx Classic/Enterprise software to achieve device discovery and data collection).

3. Controller compatibility

Compatible with I/O modules: Supports all 1769 series I/O modules, including digital input/output (such as 1769-IQ16, 1769-OB16), analog input/output (such as 1769-IF4, 1769-OF4), high-speed counter (such as 1769-HSC), temperature acquisition (such as 1769-IT6), etc;

Compatible with upper computer/terminal: Can connect Allen Bradley PanelView series HMI (such as 2711P series) and Rockwell FactoryTalk monitoring software to achieve visual operation and remote management.

Core functions and performance

1. Control ability

(1) Logic control

Programming language support: compatible with Rockwell Studio 5000 programming software, supporting four standard programming languages: ladder diagram (LD), function block diagram (FBD), structured text (ST), and sequential function diagram (SFC), to meet the programming habits of different engineers;

Task management: Supports up to 32 user tasks (including periodic tasks and event triggered tasks), with configurable task priorities (levels 0-15) to ensure priority execution of critical control tasks;

Instruction set: Built in rich instruction library, including basic logic instructions (such as contacts, coils), mathematical operation instructions (such as addition, subtraction, multiplication, division, trigonometric functions), data processing instructions (such as shift, comparison), string instructions, covering the control requirements of small and medium-sized systems.
