Fanuc A16B-3200-0110 CNC System Module

Fanuc A16B-3200-0110 CNC System Module

Core positioning and basic product information

A16B-3200-0110 is a power/signal interface module designed by Fanuc specifically for CNC systems (such as 0i series, 18i series and other high-end CNC systems). Its core function is to provide stable power distribution for CNC systems, signal interaction interfaces for external devices (such as servo drives, spindle drives, operation panels), and system operation status monitoring. It is the "signal hub" for CNC equipment (such as machining centers, lathes, milling machines) to achieve precise motion control. The basic information is as follows:

Product identification:

Product model: A16B-3200-0110 (Fanuc standard model name, "A16B" is the module series prefix, "3200" is the functional classification code, and "0110" is the specific model suffix);

Product types: CNC System Module, Power/Signal Interface Unit;

Core attribute: Industrial grade CNC specialized module, non general electrical component, required to be used in conjunction with Fanuc specific CNC system.

Key technologies and physical specifications

（1） Physical dimensions and weight

Specification category parameter value description

The horizontal dimension of the product length along the installation direction is approximately 240 mm, suitable for the installation slot of standard CNC system cabinets

The product has a vertical height of approximately 120mm and is compatible with Fanuc system modular stacking layout

The product width (depth) is approximately 180 mm, including the depth of the protruding part of the connector, and internal wiring space needs to be reserved in the cabinet

The net weight of the product is approximately 0.8 kg, excluding the net weight of packaged modules. The lightweight design facilitates the disassembly and assembly of modules inside the cabinet

（2） Electrical and functional parameters

Power input:

Main power supply: DC 24V (allowable fluctuation range ± 10%, i.e. 21.6V-26.4V), suitable for CNC system dedicated switching power supply;

Power consumption: Typical working power consumption is ≤ 15W (about 5W when unloaded, not exceeding 18W when fully loaded), to avoid power overload;

Signal interface:

Digital input (DI): 8-channel dry contact input, supporting 24V DC signal, used to receive external device status signals (such as emergency stop, limit switch);

Digital output (DO): 6-way relay output, contact capacity AC 250V/2A or DC 30V/2A, used to control external actuators (such as indicator lights, solenoid valves);

Communication interface: 1 RS485 interface (baud rate 9600-115200bps configurable), used for data exchange with servo drives and spindle drives;

Protection function:

Overcurrent protection: Built in power circuit overcurrent protection (threshold 1A), automatically cuts off the power supply when the module current exceeds the threshold to prevent burnout;

Overvoltage protection: When the input voltage exceeds 28V DC, the protection is triggered to prevent high voltage from damaging the internal circuit;

Anti interference: Complies with industrial grade electromagnetic compatibility (EMC) design, supports ± 15kV electrostatic discharge (ESD) protection, and adapts to strong electromagnetic environments of CNC equipment.

Environmental compliance and applicable conditions

Specific description of compliance category

Environmental compliance complies with the EU RoHS Directive (2011/65/EU), restricting the use of harmful substances such as lead, mercury, cadmium, etc., and meeting the environmental requirements of major global markets

Working environment - temperature: 0 ℃ -55 ℃ (no condensation, exceeding the range may cause module crash or performance degradation);

-Humidity: 5% -95% RH (non condensing, high humidity environment requires cabinet dehumidification device);

-Vibration: Within the frequency range of 5-500Hz, acceleration ≤ 5m/S ² (0.5g), avoid installing near the vibration source (such as next to an unstressed spindle motor)

Protection level IP20 (module body protection, needs to be installed in a closed CNC system cabinet, cannot be directly exposed to dust and oil pollution environment)

System adaptability and application scenarios

（1） Adapt to Fanuc CNC system

This module is only compatible with Fanuc specific series CNC systems and cannot be used across brands or series. The specific compatible models are as follows:

Mainstream adaptation systems: Fanuc 0i MF/0i TF (for machining centers/lathes), 18i MB/18i TB, 21i MB/21i TB;

Adaptive driver: It needs to be paired with Fanuc α i series servo drivers (such as A06B-6117-H106) and α i series spindle drivers (such as A06B-6134-H303), and connected to the signal and power supply through dedicated cables.

（2） Typical application scenarios

Numerical Control Machining Equipment: As the core interface module of the CNC system for machining centers, vertical lathes, and horizontal milling machines, it realizes a signal loop of "system driver actuator" to ensure accurate positioning (such as positioning accuracy ± 0.001mm) and motion control (such as feed rate 0-10000mm/min) of the equipment;
