Tektronix TBS1000B and TBS1000B-EDU series digital storage oscilloscopes

F: | Au:FAN | DA:2025-11-20 | 824 Br: | 🔊 点击朗读正文 ❚❚ ▶ | Share:

Horizontal system: Time base accuracy of 50ppm, maximum delay scanning of 100 partitions

Trigger system: Edge trigger sensitivity ≤ 1mV (50Hz bandwidth), pulse width trigger minimum 33ns

Environmental adaptability: Working temperature 0-50 ℃, humidity ≤ 85% (below 40 ℃)

2. Probe information (TPP series)

Model bandwidth attenuation ratio compensation range, maximum input voltage

TPP0051 50MHz 10:1 15-25pF 300V RMS CAT II

TPP0101 100MHz 10:1 15-25pF 300V RMS CAT II

TPP0201 200MHz 10:1 15-25pF 300V RMS CAT II

3. Equipment maintenance

Cleaning: Use a lint free cloth dipped in 75% isopropanol to wipe the outer shell, avoiding the use of abrasion cleaner

Calibration: It is recommended to conduct factory calibration annually and contact the Tech service center

Troubleshooting: Check the error log through 【 Utility 】 → 【 System Status 】. Common issues include probe not compensating and improper trigger settings
