Product Overview

The Xycom 94354-001 display screen (94354001 8503 HMI front panel) is a high-performance display screen designed specifically for industrial human-machine interaction (HMI) scenarios. As a key interactive interface of industrial control systems, it combines intuitive operating experience with powerful data processing capabilities to achieve efficient information exchange between operators and industrial equipment and systems. This display screen is widely used in industrial automation production lines, energy management systems, mechanical equipment control and other fields, providing a convenient and reliable visual operation platform for monitoring, management and control of industrial production.

Brand background

Xycom has been deeply rooted in the fields of industrial automation and embedded computing for many years, and has become a trusted brand in the industry with its profound technological accumulation and continuous innovation. Its products are known for their high reliability, powerful functionality, and excellent environmental adaptability. They have long provided solutions for industries such as industry, aerospace, and defense that require high equipment stability. They have rich technological accumulation and a good market reputation in the field of industrial automation.

technical specifications

Display parameters

Resolution: 1024 × 768 pixels, capable of presenting delicate and clear images and text information, ensuring accurate and error free display of various industrial data and operation interfaces.

Display technology: It has the characteristics of high brightness and high contrast, and can still ensure clear and visible screen content under complex lighting conditions in industrial sites (such as strong direct light and dim environments).

Touch performance

Touch control method: sensitive and precise operation, fast response speed, even if the operator wears gloves, they can easily achieve touch control operation, meeting the diverse operational needs of industrial sites.

Touch lifespan: After rigorous testing, the touch panel has an ultra long lifespan and can withstand millions of clicks and sliding operations, ensuring stability and reliability during long-term use in industrial production.

Interface Configuration

Communication Interface: Equipped with a variety of communication interfaces, including Ethernet interface (supporting high-speed data transmission, facilitating communication with industrial networks, upper computers, or other intelligent devices for remote monitoring and data exchange), RS-232/485 serial port (suitable for connecting traditional industrial instruments, PLCs, and other devices, supporting industrial communication protocols such as Modbus and Profibus), USB interface (convenient for external storage devices, keyboards, mice, etc., used for data import and export, program updates, and extended device connections).

Work environment

Working voltage: Supports a wide range of DC voltage inputs, such as DC 18-36V, to adapt to the complex and changing power supply conditions in industrial sites. It has overvoltage and undervoltage protection functions, effectively ensuring the stable operation of the display screen.

Working temperature: The working temperature range is [-20 ℃ -70 ℃], which can work normally in harsh industrial environments such as high and low temperatures

Protection level: up to IP65 or other protection level standards, with dustproof and waterproof capabilities, can effectively resist the invasion of pollutants such as dust, oil, water droplets, etc. in industrial sites, ensuring the long-term stable operation of the display screen in harsh environments.

install

Installation method: Supports various installation methods such as panel embedded installation, wall mounted installation, etc. The installation process is simple and convenient, and can be flexibly selected according to actual application scenarios

Core functions

Data visualization display: Display various types of data in the industrial production process (such as equipment operating parameters, production progress, quality inspection data, etc.) in real-time on the screen in the form of intuitive charts (such as line charts, bar charts, pie charts), dashboards, text, etc., helping operators quickly understand the production status, discover problems in a timely manner, and make decisions.

Human computer interaction operation: Through touch screens or external input devices such as keyboards and mice, operators can easily control industrial equipment and systems, such as setting device operating parameters, starting/stopping devices, switching production modes, etc. The operation interface adopts a graphical design, which is user-friendly and the operation process is simple and easy to understand, reducing the learning cost of operators.

Alarm and prompt function: Built in alarm system. When industrial equipment or systems encounter abnormal situations (such as parameter exceeding limits, equipment failure), the display screen immediately issues an alarm in the form of sound and light alarm, pop-up prompt, etc., while displaying detailed alarm information (such as alarm type, occurrence time, location, etc.), reminding operators to handle it in a timely manner to avoid accidents.

Data Storage and Management: Supports local data storage, allowing key data in industrial production processes (such as historical operating parameters, alarm records, etc.) to be stored in built-in or external storage devices on the display screen, facilitating later queries, analysis, and traceability. At the same time, data can be uploaded to the upper computer or cloud server through communication interfaces to achieve centralized management and remote access of data.

Multi language support: Supports switching between multiple language interfaces, such as Chinese, English, German, etc., to meet the usage needs of different regions and operators, making it easy for multinational enterprises or international industrial projects to apply.
