YOKOGAWA FIO I/O module with built-in safety barrier
Product Name: FIO I/O Module with Built in Safety Barrier
Applicable environment: Installed in Zone 2 or Division 2 areas, it can connect to on-site devices located in Zone 0, 1, or Division 1 areas
Compliance standards: Compliant with ISA S71.04 class G3, meeting ATEX and FM certification requirements (subject to corresponding certificate "special conditions")
Environmental adaptability: working/storage temperature * * -20~70 ℃**
Isolation characteristics: The on-site interface and system have galvanic isolation, while there is no isolation between channels
Key note: When multiple channels are short circuited, all channels of the module will lose their intrinsic safety function
Applicable environment: Installed in Zone 2 or Division 2 areas, it can connect to on-site devices located in Zone 0, 1, or Division 1 areas
Compliance standards: Compliant with ISA S71.04 class G3, meeting ATEX and FM certification requirements (subject to corresponding certificate "special conditions")
Environmental adaptability: working/storage temperature * * -20~70 ℃**
Isolation characteristics: The on-site interface and system have galvanic isolation, while there is no isolation between channels
Key note: When multiple channels are short circuited, all channels of the module will lose their intrinsic safety function
Redundant configuration: Install 2 modules in adjacent slots (odd even slots), supporting dual redundant configuration
Model code and ordering
（1） Encoding rules (universal structure)
Encoding type meaning optional values
Main model module type identification ASI133 (analog input), ASI533 (analog output), AST143 (TC/mV input), etc
Suffix code 1 Function type - S (standard type), - H (with HART communication)
The suffix code 2/3 has a fixed code of 0
Option code terminal types/SA3S0 (analog input standard terminal),/SA3D0 (analog input redundant terminal), etc. (distinguished by module type)
（2） Ordering requirements
It is necessary to clearly specify the main model+suffix code+option code, for example: Analog input module with HART communication and standard terminals: ASI133-H00/SA3S0
