DESCRIPTION

The Reliance® FlexPak 3000 is part of the Reliance Electric family of variable speed AC and DC drives. The FlexPak 3000 digital DC drive features a unique, ergonomic user interface for easy installation, start-up, application, and maintenance. Its unique design uses the latest digital, micro-semiconductor and circuit technology for an exceptional combination of simplicity, flexibility, and reliability in a compact package.

Simple

• Readily accessible control, signal, and field wiring for streamlined installation

• User-friendly, graphical displays and a remote keypad using plain text  instructions provide fast and easy set-up

• Five languages, accessible with a single keystroke, for displaying diagnostics, status information, and “help” tex

Compact.

• Extensive use of molded parts enable feature-rich power density with a  small footprint

• Space-saving package facilitates field wiring, mounting, modification, and maintenance

• Standard chassis design converts easily to NEMA 1 enclosure using NEMA 1  conversion kits or, for high HP controllers, floor-mount NEMA 1 enclosures

Reliable.

• Advanced high-density power semiconductor devices, surface mount, and  sub-micron ASIC technology for exceptional dependability

• Sophisticated design uses fewer parts for extended performance and reduced  maintenance requirements

Dependable AC Supply  For Optimum Reliability

• 50/60 Hz AC line frequency input

• Phase insensitive AC line input

• Semiconductor fuse protection

• AC “N” contactor (DC “M” above 300 HP)

Expanded Offering of Digital Signals For Optimum Flexibility

• Coast, stop, auto/manual, forward/reverse, jog, run, and  stop inputs

• Motor thermostat diagnostic input

• Brush wear diagnostic input

• Customer interlock diagnostic input

• Drive running contact output

• Drive alarm contact output

• Drive fault contact output

Versatile Power Capabilities For Diverse Application Requirements

• Full-wave, full control 6-Pulse power conversion for  smooth efficient operation and high performance

• Burst firing of SCRs • Non-regenerative or regenerative (required for reversing)  controller

• Capable of 150% full-load current for one minute

• DC inverting fault protection on regenerative controllers

User-Friendly Quick Start Menu  For Easy Set-Up and Application

Adjustable parameters include:

• Maximum speed

• Minimum speed

• Linear acceleration

• Linear deceleration

• Current limit (positive and negative on  regenerative modules)

• I/R compensation (voltage regulated drives)

• Jog speed

• Jog acceleration/deceleration rate

• Reverse disable on regenerative drives
