UNIOP CP05R-04-0045 HMI Operator Panel
The UNIOP CP05R-04-0045 is a high-performance operator interface panel from the CP series, designed to provide intuitive machine control and visualization in industrial environments. Featuring a 5.7-inch color TFT LCD with resistive touch technology, it offers clear graphical representation and reliable operation even in harsh conditions.
Key Features
5.7" TFT color display, 320x240 pixels (QVGA)
Resistive touch screen with high durability
Multiple communication ports: Ethernet 10/100, RS232, RS422/485
USB host and device ports for data transfer and peripheral connection
Wide input voltage range: 24 V DC ±20%
Compact design with IP65 front panel protection
Supports UNIOP’s powerful configuration software (e.g., UniOP Designer Studio)
Technical Specifications
Display type: TFT LCD, 65k colors
Backlight: LED, 50,000 hours typical
Processor: 32-bit RISC, 400 MHz
Memory: 64 MB RAM, 128 MB Flash
Real-time clock with battery backup
Operating temperature: -10°C to +50°C
Dimensions: 204 x 150 x 48 mm (WxHxD)
Applications
The CP05R-04-0045 is ideal for use in packaging machines, textile machinery, plastic processing, food processing equipment, and general automation systems. Its robust construction and wide connectivity make it suitable for both standalone and networked applications.
Software and Programming
The panel is programmable using UNIOP’s Designer Studio software, which provides a comprehensive library of graphical objects, alarms, recipes, and trends. It supports communication with major PLC brands via built-in drivers, including Siemens, Allen-Bradley, Mitsubishi, and Modbus.
With its reliable performance and flexible connectivity, the UNIOP CP05R-04-0045 enhances operator efficiency and machine uptime in demanding industrial settings.
