Moxa EDS-408A series industrial Ethernet switch

MTBF (Mean Time Between Failures): Conventional models have a maximum of 1339439 hours, while some models have a minimum of 989940 hours, in compliance with Telcordia (Bellcore) and GB standards.

Key to Model Classification and Selection

There are a total of 22 sub models in the entire series, with core selection dimensions including port configuration, operating temperature, and industrial protocol. Some mainstream models are shown in the table below:

The model type represents the core differences of the model

Full RJ45 port EDS-408A (standard temperature) with 8 RJ45 ports, no fiber optic ports, suitable for short distance wired interconnection

EDS-408A-T (wide temperature range) as above, suitable for low/high temperature industrial environments

Equipped with multi-mode fiber EDS-408A-MM-SC, 6 RJ45+2 multi-mode SC fibers, with a transmission distance of 4km, suitable for medium to short distance fiber networking

Equipped with single-mode fiber EDS-408A-SS-SC, 6 RJ45+2 single-mode SC fibers, with a transmission distance of 40km, suitable for long-distance (such as cross regional interconnection in the factory area) interconnection

Industrial protocol customization EDS-408A-EIP 8 RJ45, default enabled EtherNet/IP protocol

EDS-408A-PN 8 RJ45, default enabled PROFINET protocol

Hybrid fiber type EDS-408A-1M2S-SC 5 RJ45+1 multimode SC+2 single-mode SC, meeting the needs of medium to short/long-distance fiber

Selection tip: The model with "- T" at the end is for wide temperature version, and with "-48" is for bipolar voltage version. It needs to be selected according to the actual environmental temperature, power supply type, and transmission distance requirements.

Certification and Compliance

Safety certification: EN 60950-1, UL 508, UL 60950-1;

Special scenario authentication:

Hazardous environment: ATEX Class I Division 2 (some models);

Maritime: NK, DNV-GL (some models);

Railway: EN 50121-4;

Traffic control: NEMA TS2;

Environmental testing: Compliant with IEC 60068 series (free fall, impact, vibration).
