TEKTRONIX 5A38 Differential Amplifier Plug-in Module
Product Introduction: The Tektronix 5A38 is a specialized plug-in amplifier module compatible with the versatile 7000 Series oscilloscope mainframes. It provides high-sensitivity, differential input capability, allowing engineers to accurately measure small signal voltages in the presence of common-mode noise. Its design is optimized for applications requiring precise observation of fast, low-level waveforms in fields such as research, telecommunications, and analog circuit design.
Overview and System Integration
The Tektronix 5A38 embodies the modular philosophy of the legendary 7000 Series oscilloscope system. It is not a standalone instrument but a dedicated vertical amplifier plug-in that slots into a compatible 7000 Series mainframe (such as the 7704A or 7904). This system architecture allows users to configure a test instrument tailored to specific needs by combining various plug-ins for amplification, timebase, and other functions. The 5A38's primary role is to condition and amplify low-level analog signals before they are processed and displayed by the mainframe's CRT and measurement systems, effectively extending the oscilloscope's capability to handle challenging measurement scenarios.
Core Technical Features and Measurement Advantages
Differential Input and High Common-Mode Rejection
The defining feature of the 5A38 is its true differential input. Unlike a standard single-ended amplifier, it measures the voltage difference between its two input terminals (High and Low) while actively rejecting any voltage common to both. This results in a high Common-Mode Rejection Ratio (CMRR), which is crucial for accurately measuring small signals riding on large DC offsets or buried in electrical noise, such as those found in balanced communication lines or power supply control circuits.
High Sensitivity and Wide Bandwidth
The module offers exceptionally high sensitivity, allowing it to resolve minute voltage changes. It maintains this sensitivity across a wide bandwidth, enabling the observation of fast transient details in low-amplitude signals. This combination is vital for tasks like characterizing noise in precision analog circuits, analyzing jitter in clock recovery systems, or measuring the performance of high-gain amplifier stages.
Flexible Attenuation and Calibration
The 5A38 provides precise, calibrated deflection factors (volts per division). Users can select appropriate attenuation levels to optimally scale the signal on the oscilloscope's display. The module is designed for stable, repeatable performance and typically includes adjustment provisions for calibration to ensure long-term measurement accuracy, a critical requirement for quantitative analysis.
Representative Technical Specifications
The following specifications are characteristic of the Tektronix 5A38 differential amplifier module's performance profile.
Primary Applications and Engineering Use Cases
The Tektronix 5A38 is indispensable in scenarios where signal integrity and precision are paramount.
Precision Analog Circuit Debug: Measuring noise, offset voltages, and small-signal swings in operational amplifiers, instrumentation amplifiers, and sensor interfaces.
Differential Communication Line Analysis: Observing signal integrity on balanced lines (e.g., RS-422, CAN bus) without introducing ground loop errors.
Power Electronics Research: Safely measuring switching node voltages and current sense signals in switch-mode power supplies and motor drives where high common-mode voltages are present.
Physics and Materials Science Experiments: Detecting and amplifying low-level signals from transducers, detectors, or probes in laboratory setups.
Audio and Low-Frequency Equipment Design: Analyzing distortion, noise floor, and performance of high-fidelity audio equipment and low-frequency analog filters.
Operational Context and Historical Significance
Operating the 5A38 requires integration into a fully configured 7000 Series mainframe. When installed, it becomes the vertical deflection source for one channel of the oscilloscope. The mainframe provides power, the triggering system, the horizontal timebase, and the display. This modular approach, pioneered by Tektronix, offered unparalleled flexibility for mid-to-late 20th-century engineers. While modern digital oscilloscopes often integrate similar differential measurement capabilities, the 5A38 and the 7000 Series represent a peak of analog instrument design, valued for their immediate visual feedback, high waveform update rates (akin to an analog scope), and exceptional signal fidelity within their bandwidth.
Conclusion
The Tektronix 5A38 differential amplifier plug-in is a classic tool of precision measurement. Its ability to isolate and accurately amplify small differential signals made it a cornerstone for advanced electrical engineering work in its era. For those maintaining, restoring, or utilizing vintage 7000 Series systems, the 5A38 remains a powerful and relevant module for specific high-fidelity measurement tasks. It stands as a testament to an engineering philosophy that prioritized modularity, performance, and dedicated hardware solutions for solving complex measurement challenges.
