GE 269Plus Motor Management Relay

GE 269Plus Motor Management Relay

DESCRIPTION

The GE Multilin model 269 Plus Motor Management Relay® is a modern microcomputer-based product designed to provide complete, accurate protection for industrial motors and their associated mechanical systems. The 269 Plus offers a wide range of protection, monitoring, and diagnostic features in a single, integrated package. All of the relay setpoints may be programmed in the field using a simple 12-position keypad and 48- character alphanumeric display. A built-in “HELP” function can instruct the user on the proper function of each of the programming keys and on the meaning of each displayed message.

PROTECTION FEATURES

• Overloads

• Stator Winding Overtemperature (Alarm, High Alarm and Trip)

• Multiple Starts

• Short Circuit

• Locked Rotor

• Rapid Trip/Mechanical Jam

• Unbalance/Single Phasing

• Ground Fault (Alarm and Trip)

• Bearing Overtemperature (Alarm and Trip)

• Undercurrent (Alarm and Trip)

• Variable Lock-Out Time

• Phase Reversal (Meter Option)

OPERATIONAL FEATURES

• Microcomputer controlled

• Keypad programmable

• 48 character alphanumeric display

• Built-in "HELP" function

• Eight selectable standard overload curves

• User-defined custom overload curve capability, FlexCurve™

• Continual relay circuitry self-check

MONITORING AND DISPLAY FEATURES

• Negative sequence phase current unbalance measurement

• Ground fault (earth leakage) current measurement

• Up to six stator RTD inputs

• Four additional RTD inputs

• Monitoring of motor ambient air temperature

• Display of all SETPOINTS or ACTUAL VALUES upon request

• Display of relay TRIP/ALARM and HELP messages

COMMUNICATIONS AND CONTROL FEATURES

• One latched, main trip relay

• One alarm relay

• Two auxiliary relays

• Emergency restart capability

• Pre-trip alarm warnings

• 4-20mA output of motor current as a percentage of full load, motor thermal capacity, hottest stator RTD temperature, percentage of phase CT secondary current, or bearing RTD

• Optional single-shot restart on running overload trip

• Speed switch, differential relay, and spare input

• RS485 port for connection to programmable controllers and computers.
