KONGSBERG HiPAP System Operation and Maintenance Guide

来源: | 作者:FAN | 发布时间 :2026-05-12 | 5 次浏览: | 🔊 Click to read aloud ❚❚ ▶ | Share:

Check for capacitor bulges and connector oxidation on the internal boards of the transceiver unit.

Verify the overall accuracy of the system through a known responder (such as a reference responder suspended at a depth of 1 meter on the ship's side): compare the distance calculated by APOS with the actual physical distance, and the error should be within<0.2% (for example, the error at 100 meters should be<0.2 meters).
