MOTOROLA MVME2400 series VME processor module

MOTOROLA MVME2400 series VME processor module

In demanding fields such as industrial control, military defense, aerospace, and telecommunications infrastructure, system reliability, real-time performance, scalability, and long-term availability are core considerations. The VME bus architecture, with its robust mechanical structure, excellent anti-interference capability, and mature ecosystem, has been the backplane interconnect standard for these critical mission systems for decades. The MVME2400 series of single board computers (SBC) launched by Motorola (now part of NXP) Computer Group is a high-performance model under this tradition. It cleverly combines powerful PowerPC processing capabilities, flexible industrial standard expansion interfaces, and a robust VME platform, providing a powerful core engine for building complex and reliable high-end embedded computing systems.

Core Power: Balancing High Performance and Low Power Consumption

The core of the MVME2400 series was Motorola's leading PowerPC 750 at the time ™ Series 32-bit microprocessor. This processor is renowned for its excellent performance per watt, offering multiple clock frequency options including 233 MHz, 350 MHz, and even 450 MHz to meet the tiered computing performance requirements of different applications. The on-chip integration of 32KB instruction cache and 32KB data cache (L1) ensures efficient data supply to the core execution unit. It is worth mentioning that the module comes standard with up to 1MB of backend L2 cache, which runs at half speed or higher on the frontend bus (such as up to 180 MHz when paired with a 450 MHz processor), effectively buffering the speed gap between the processor and main memory. This is crucial for improving overall system performance, especially for processing data intensive tasks.

In terms of main memory, MVME2400 supports PC100 synchronous dynamic random access memory (SDRAM) with ECC (error checking and correction) protection, with a capacity that can be flexibly configured from 32MB to 512MB. The ECC function can detect and correct single bit errors and double bit errors, greatly enhancing the data integrity and reliability of the system in harsh electromagnetic environments or long-term operation. Its 64 bit wide, single cross access memory architecture further ensures a high bandwidth data channel with the processor.

Architecture Essence: PowerPlus II and Highly Decoupled Design

The outstanding performance of MVME2400 is not only due to a powerful CPU, but also to the true behind the scenes "PowerPlus II" architecture. As a second-generation optimized architecture, PowerPlus II aims to fully utilize the potential of PowerPC processors, PCI local buses, and VME system buses.

The core idea of this architecture is "decoupling" and "optimization". It separates the processor subsystem and the PCI local bus subsystem relatively independently through an efficient processor/memory to PCI bus bridge chip. This design avoids frequent stagnation of high-speed processors due to waiting for relatively low-speed I/O operations, achieving parallel processing of computation and I/O. At the same time, it supports local bus operation at 100 MHz and adopts SDRAM technology, resulting in lower access latency and higher bandwidth between the processor and memory.

Its advanced VME interface design is equally critical. It adopts the Tundra Universe II VMEbus controller, which is fully compatible with the ANSI/VITA 1-1994 VME64 standard and supports efficient data transfer modes such as block transfer (BLT) and unaligned transfer (UAT) for A32/D64. It also optimizes the access path from the PCI bus to the VME bus, minimizing the impact of PCI latency on VME transactions. This enables MVME2400 to act as a powerful VME master module to initiate high-speed data block transmission, as well as efficiently respond to access from other masters within the system as a slave device.

Expanding Soul: Dual PMC Slot and VME64x Interface

Flexibility is the guarantee for the long-term vitality of embedded systems. The MVME2400 offers a forward-looking design in this regard: two PCI Mezzanine Card (PMC) expansion slots that fully comply with the IEEE P1386.1 standard.

PMC module is a high-performance, miniaturized I/O expansion standard widely used in the embedded field. The two PMC slots of MVME2400 can support one dual width or two single width PMC modules, and provide I/O output through the front panel or VME P2 connector. This design means that users can select and install the corresponding PMC module based on specific application requirements - whether it's additional network ports, specific serial/parallel interfaces, image capture cards, or custom dedicated I/O - without the need to redesign or replace the entire processor motherboard. This not only shortens the development cycle and reduces the initial design difficulty, but more importantly, throughout the entire lifecycle of the product, the PMC module can be replaced to adapt to changes in I/O requirements, significantly reducing the total cost of ownership (TCO) of the system.
