REXROTH BTV04.2 Micro Control Panel Functions and Applications

2. Typical Connection Examples

BTV04.2 can be directly connected to various Indramat controllers:

MTC200-P/MTA200-P/IS200-P: Connected via RS485 interface (X40/X41 or X16), supports up to 2 BTVs in parallel

CLC-D, Ecodrive3, ELC: connected via a single bus

PPC-R, CLM, DLC: connected via standard RS485 interface

All communication cables are recommended to use shielded twisted pair cables, with a length not exceeding 400 meters (RS485) or 10 meters (RS232), and terminal resistors should be installed at both ends of the bus if necessary.

First debugging and software loading

1. Required tools

BTV04.2 Control Panel and Power Supply

Connect cable IKB0012 (RS232 interface)

PC with "Dolfi" flash tool installed (Windows 3.11/95/98/NT)

Application software disk (including. IBF files)

2. Loading steps

Connect BTV04.2 to PC via IKB0012 cable

Power on BTV04.2, the screen displays the Indramat logo

Run Dolfi tool on PC, set COM port and baud rate (connection: 9600 bps; Download: 38400 bps) and destination address (default is 03)

Select 'Serial Connect' to establish a connection

To back up the original software, select "Backup" and save it as BAK file

Select 'Send' to load the new software, and the progress bar will display the transmission status

After completion, select 'Disconnect' and BTV04.2 will automatically restart and run the new software

3. Bootloader function

After powering on the device, first run the Bootloader to check if there is any valid software in the Flash. If there is no valid software or the software is damaged, the screen will display "dolfi loader active". At this time, you can press the F1 key to enter service mode, view version information or reload the software.

Attachments and ordering information

BTV04.2 provides a variety of matching cables and connectors, such as:

IKB0012: RS232 programming cable

IKB0017/0018/0019: RS485 communication cable (up to 400 meters long)

INS0619/K01: RS485 connector with terminal resistor

In terms of software, users can customize the interface and logic through the "ScreenManager" tool, which supports interaction with Indramat's full range of controller variables.
