Xycom XVME-100 RAM Memory Module

Xycom XVME-100 RAM Memory Module

Storage capacity and technology type

Capacity specifications

XVME-100 typically offers multiple storage capacity options, commonly including 32MB, 64MB, 128MB, etc., to meet the data storage requirements of different application scenarios. For example, in industrial automation control systems, if there is a large amount of real-time data caching and processing involved, the larger 128MB specification can ensure efficient system operation and avoid data loss or processing delays caused by insufficient memory.

Technical type

This module adopts dynamic random access memory (DRAM) technology, which has the characteristics of high cost-effectiveness and fast read and write speed. It can quickly respond to the system's read and write requests for data, ensuring the smooth operation of the computer system. In some industrial control scenarios that require high real-time performance, such as real-time monitoring and control of automated production lines, DRAM technology can process sensor data in a timely manner, enabling the control system to respond quickly.

Electrical characteristics

Working voltage

The working voltage of XVME-100 is generally 5V DC (direct current), which is a common voltage value that meets industrial standards and is easy to adapt to the power supply system of other industrial equipment, ensuring stable power supply in industrial environments. In complex electrical environments such as factory workshops, a stable 5V power supply can ensure the normal operation of memory modules and reduce the risk of faults caused by voltage fluctuations.

Power consumption

The power consumption of this memory module is relatively low, taking the 128MB specification as an example, the typical power consumption is about 2-3W. The low-power characteristic not only helps to reduce the energy consumption of the entire system, but also reduces heat generation and improves the stability of the device during long-term operation, especially suitable for applications such as industrial control cabinets with limited heat dissipation conditions.

Interface and Physical Characteristics

Interface type

XVME-100 adopts the VME (Versa Module Eurocard) bus interface, which has advantages such as high reliability and high-speed data transmission capability. The VME interface supports multi master device operation, with a data transmission rate of up to 40MB/s, which can meet the demand for fast transmission of large amounts of data in industrial automation systems. For example, in industrial data acquisition systems, the collected data can be quickly transmitted to the processor for processing.

Physical dimensions

The module size follows the 6U specification of the VME standard, which is 340mm long and 233.35mm wide. This standardized size design makes it easy to install on various chassis or backboards that comply with the VME standard, with good universality and interchangeability, making it convenient for system integrators to build and maintain the system.

Weight

The weight of XVME-100 is relatively light, approximately between 200-300 grams, with slight differences in specific weight due to capacity and internal component configuration. The lighter weight makes the operation more convenient during equipment installation and maintenance, reducing the load-bearing pressure on the equipment installation structure.

Performance parameters

Read and write speed

Its read speed is usually between 10-20ns (nanoseconds), and the write speed is about 15-25s. Fast read and write speeds are crucial for applications that require frequent access to data, such as in industrial real-time database systems, where new data can be quickly written into memory and historical data can be quickly read for analysis, providing timely and accurate data support for industrial decision-making.

Data transmission rate

With the help of the VME bus interface, the data transmission rate of XVME-100 can reach 40MB/s, enabling high-speed data exchange with other devices in the system (such as processors, storage devices, etc.), ensuring the data processing efficiency of the entire industrial system. In the control system of industrial automation production lines, high-speed data transmission enables the controller to quickly obtain sensor data and issue control instructions in a timely manner, ensuring the efficient operation of the production line.

Environmental adaptability

Working temperature range

XVME-100 can operate within a wide temperature range, typically from -40 ° C to+85 ° C. This allows it to adapt to various harsh industrial environments, whether in cold northern industrial sites or hot southern factory workshops, ensuring stable operation of industrial systems without being affected by environmental temperature.

Humidity range

This memory module can operate normally in an environment with a relative humidity of 5% -95% (without condensation). In some industrial scenarios with high humidity, such as textile factories, food processing plants, etc., it can effectively avoid circuit short circuits or data errors caused by humidity issues, ensuring the reliability of the system.
