  • GE DS200SDCCG4A Drive Control Card
    ❤ Add to collection
  • GE DS200SDCCG4A Drive Control Card

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    GE DS200SDCCG4A Drive Control Card

    • ¥22000.00
      ¥34670.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:2.500KG
    • Quantity:
    • (Inventory: 33)
Description

GE DS200SDCCG4A Drive Control Card


GE DS200SDCCG4A Drive Control Card

Part Number DS200SDCCG4A Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark V Function Module Availability In StockDS200SDCCG4A is a Drive Control Card manufactured and designed by General Electric as part of the Mark V Series used in gas turbine Control Systems. The SDCC houses the main software and circuitry for a drive or exciter. Three 16-bit microprocessors and related circuits make up the SDCC, which are connected through dual-ported RAM. Dual-ported RAM [DPR] is RAM set up as memory arrays that two microprocessors may access both independently and concurrently. Additionally, the SDCC has interface circuitry that joins with other boards to create different kinds of ac and dc motor drives.

The interface circuitry manages and processes consumer I/O, drive, and motor signals. DS200SDCCG4A Features Processor for Drive Control (DCP). An 80C186 microcontroller (U1) uses both digital and analog I/O and has many built-in peripheral features. These features include the direct memory access (DMA) controller, timers/counters, an interrupt controller, wait-state generators, and address decoding for chip select. User interfaces, external regulating loops (such as speed and location), and system-level operations make up DCP software. Processor for motor control (MCP). a microcontroller (U21) with an 80C196 processor that has high-speed I/O, analog I/O, traditional digital I/O, timer/counters, and a watchdog timer. Inner loops like current regulators and motor/technology-specific features like dc phase control, ac motion control, and ac general purpose make up MCP software. Processor for co-motion (CMP). For motor control algorithms that are too sophisticated for the MCP, a TMS320C25 digital signal processor (U35) executes math-intensive operations. Only when the drive requires the extra processing power does the SDCC use this processor and the electronics that go along with it. The only devices with which the CMP interfaces are its dual-ported RAM and EPROM.

Five memory chips total, four EPROMs (U11, U12, U22, and U23) with factory-programmed configuration data and one EEPROM (U9) with field-adjustable parameters, make up the onboard software for the DS200SDCC card. On the SDCC, sockets house these memory chips. Applicable to TC2000 turbines (same as G1A except with enlarged EE parameter storage area and different firmware) Test Points In order to test and troubleshoot, the SDCC has onboard test points. Metal posts known as test points can be found along particular signal pathways. Any measuring device, such as an oscilloscope, can be used to measure or observe these signals. DS200SDCCG4A Configurable Hardware The SDCC includes configurable hardware that must be set correctly for the application: Berg-type (manually movable) hardware jumpers, identified by a JP nomenclature Wire jumpers, identified by a WJ nomenclature These jumpers are utilized for user application options or factory testing. The majority of the jumper options are pre-set at the factory.

These factory fixed positions are listed on the test data sheets that come with each controller (in the drive/exciter door pocket). Software Configuration Tools The SDCC requires the use of the ST2000, GE Control System Toolbox, or LynxOS Drive Configurator for any software modification, download, or replacement. For any software modifications, the ST2000, GE Control System Toolbox, or LynxOS Drive Configurator instruction book, a suitable PC, and the relevant drive/exciter instruction book are also needed. The ST2000 software toolkit for setting GE DIRECTO-MATIC 2000 control equipment runs on the DOS operating system. The GE Control System Toolbox is a set of Windows-based software tools for setting up GE DIRECTO-MATIC 2000 control equipment. The GE DIRECTO-MATIC 2000 control equipment can be configured using a collection of software tools called the LynxOS Drive Configurator. It is made to function on a personal computer (PC) running the LynxOS operating system.

Benefits

 Single slot CPU

 Provides 1 Mbyte of battery-backed memory in the same slot (up to 512 Kbytes available for use by ladder diagram application program)  Supports floating point calculations

 Up to 12K discrete inputs and outputs (any mix - simplex mode only); 2048 voted discrete inputs, 2048 voted discrete outputs Up to 8K analog inputs (simplex mode only) and 8K analog outputs (simplex mode only); 1024 voted analog inputs

 0.4 microseconds per boolean function

 64 MHz, 80486DX2 microprocessor

 Supports IC660/IC661 I/O (and IC697 I/O in simplex mode only)

 Programmed by MS-DOS

, or Windows

 software products running on Windows

 95 or Windows NT

 over Ethernet TCP/IP or through the SNP port.

 Configurable data and program memory

 Battery-backed calendar clock

 Three position operation mode switch

 Password controlled access

 Remote programmer keyswitch memory protection

 Four status LEDs

 Software configuration (No DIP switches or jumpers)

 Reference information inside front door

 In-system upgradable firmware
