Eaton HMI10CE / HMI10CE02 – 10.4" Touch Screen HMI

Display and Operation

The 10.4" TFT screen offers SVGA resolution (800 x 600 pixels) with 65,536 colors, ensuring sharp graphics and excellent readability from various viewing angles. The analog resistive touch screen is sensitive and durable, supporting gloved operation. The front panel is rated IP65, providing protection against dust and water jets, making it suitable for wash‑down environments.

Connectivity and Communication

• Ethernet: 10/100 Base-T port for programming, remote monitoring, and data exchange with PLCs or higher‑level systems.

• Serial Ports: Two configurable RS232/RS485 ports for connecting to legacy controllers, drives, or barcode scanners.

• USB: Host and device ports for program upload/download, data logging to USB flash drive, and connecting peripherals (keyboard, mouse).

• Optional Fieldbus: Some variants may include CANopen or Profibus modules (check model specifics).

Software and Programming

The HMI10CE is programmed using Eaton’s Galileo or other compatible HMI software (e.g., CODESYS based). It supports a vast library of communication drivers for major PLC brands (Siemens, Rockwell, Mitsubishi, etc.) and allows creation of sophisticated operator screens with animations, recipes, and trend charts. The built‑in web server enables remote access via standard browsers.

Technical Specifications

• Display: 10.4" TFT, 800 x 600 pixels, 65k colors, LED backlight

• Touch: Analog resistive, 1 million touches lifetime

• Processor: 32-bit RISC (typical 400 MHz)

• Memory: 64 MB RAM, 128 MB Flash (expandable via SD card)

• Interfaces: 1 x Ethernet, 2 x serial (RS232/485), 2 x USB, 1 x audio out (optional)

• Power Supply: 24 V DC (18‑32 V DC)

• Protection: IP65 (front), IP20 (rear)

• Operating Temperature: 0°C to +50°C

• Dimensions: 311 x 239 x 56 mm (cut‑out: 298 x 226 mm)

Typical Applications

• Packaging lines – central operator station

• Food and beverage processing – hygienic interface

• Pharmaceutical production – recipe management and batch control

• Water treatment plants – SCADA front end

• Machine tools – CNC and auxiliary control

Durability and Compliance

The HMI10CE is built to withstand harsh industrial conditions, with vibration and shock resistance according to IEC 60068‑2. It carries CE, UL, and cUL marks, ensuring compliance with international safety standards. The unit’s fanless design and solid‑state components guarantee long‑term reliability.

With its large display, robust construction, and flexible connectivity, the Eaton HMI10CE / HMI10CE02 is an excellent choice for machine builders and end users seeking a powerful and reliable operator interface.
