Omron NSH5-AL001 NS Series Handheld Programmable Terminal

The Omron NSH5-AL001 is a handheld programmable terminal from the NS series of human-machine interface (HMI) products. This mobile operator panel is designed for use in applications where a stationary HMI is insufficient, allowing operators to interact with the control system from different locations around a machine or machine line. The NSH5 series combines a touch screen display with physical safety devices including an emergency stop switch and a three-position enabling device, making it suitable for use in teach pendant applications where operators must enter hazardous areas for setup or maintenance tasks.

Display and User Interface

The NSH5-AL001 features a high-resolution color TFT LCD display with LED backlight technology. The touch screen interface supports fingertip operation, providing intuitive navigation through machine status displays, parameter configuration screens, diagnostic pages, and alarm logs. The displayed information includes measured process values, equipment operating status, maintenance reminders, and production count data in a graphical format. The terminal offers high-speed processing and can display data from the controller memory in real time. Available display sizes range from 5.7 inches to 12.1 inches depending on model variant. The handheld ergonomic design includes a handle integrating the enabling device and emergency stop pushbutton, enabling safe one-handed operation in demanding industrial applications.

Integrated Safety Functions

The NSH5-AL001 incorporates safety features specifically designed for teach pendant and mobile operator station applications. An emergency stop (E-stop) switch is mounted on the top of the handheld enclosure, designed for rapid actuation in hazardous conditions. This switch must be connected to the machine safety circuit and is intended to remove hazardous energy when pressed. A three-position enabling switch is integrated into the handle, providing a spring-return enabling device requiring sustained operator action to maintain the machine in a potentially hazardous mode such as program verify or manual axis movement. The enabling device has a center-ON position, with both released and fully-pressed positions causing the safety outputs to de-energize, complying with machine safety standards for enabling devices. These safety features are redundant, ensuring detection of single faults in the safety circuit.

Connectivity and Communication

The NSH5 series communicates with Omron PLC controllers via standard industrial network protocols. The handheld terminal connects to the control cabinet through a flexible cable that carries both power and communication signals. A variety of communication interfaces are supported by the NS series, allowing integration with Omron CS/CJ series PLCs, CJ2 series, and other controllers. The connection is established via the RS-232C or RS-422A/485 serial interfaces, enabling both programming access and operational data exchange. The connection is suitable for applications where the operator requires direct interaction with the controller for functions such as program test, parameter adjustment, and fault confirmation.

Construction and Environmental Suitability

The NSH5 handheld enclosure is constructed to withstand the physical demands of regular handling in industrial environments. The housing is rugged and resistant to the effects of typical industrial contaminants including dust, oil mist, and moisture. The touch screen surface is designed for resistance to scratching and chemical exposure. The cable entry points provide strain relief, preventing damage to internal connections during movement. The weight and balance are optimized for comfortable extended use during machine commissioning or setup procedures. The terminal can be stored in a docking station when not in use, providing battery charging and cable management.

Status Indication and Operator Feedback

The NSH5-AL001 provides comprehensive status indication through its display and integral LEDs. The touch screen shows operator prompts, machine information, and feedback when making settings or confirming operations. The screen can display text in multiple languages, supporting international machine deployments. When combined with Omron CJ2 CPU units, the handheld terminal can also display data from the controller memory at high speed. The emergency stop switch and enabling device provide positive tactile feedback, and the switch status is reflected in both the HMI display and the connected safety circuit.

Application Areas

The NSH5-AL001 is intended for use in applications requiring mobile operator access to PLC control systems. Typical uses include robotic teach pendant operations, machine setup and calibration during changeovers, maintenance access to remote sensors or actuators, and diagnostic troubleshooting where the operator must view the machine action while adjusting parameters. Industries where this product is commonly applied include automotive manufacturing for robot teaching and maintenance of transfer lines, packaging machinery for setup of new product formats requiring multi-point access, and material handling systems.
