Equipment Overview

Core function: CI855 is a communication interface used to implement the MasterBus 300 (MB300) communication protocol in AC 800M controllers. This protocol is suitable for communication between controllers and operator stations in devices based on Advant OCS and equipped with Master software. It is connected to the CEX bus through the backplane.

Supporting components: The TP853 motherboard is equipped with RJ45 connectors with two Ethernet ports, supporting network redundancy and providing a convenient DIN rail installation method.

Key advantage: Supports peer-to-peer communication between new factory areas using AC 800M controllers and existing controllers based on MB300, such as Advance Controller 410, Advance Controller 450, MasterPiece 200/1, etc.

Basic information

Product Code: 3BSE018106R1

Communication protocol: ABB's MasterBus 300

Master slave attribute: Master device

Transmission speed: 10 Mbit/s, 200 datasets/second

Line redundancy: supported

Module redundancy: not supported

Hot swappable: Supports

Used in conjunction with HI controller: Supports

CE certification: Yes

Classification Society Certification: BV, DNV-GL, LR

RoHS compliance: Compliant with Directive 2011/65/EU (EN 50581:2012)

WEEE Compliance: Compliant with Directive/2012/19/EU

Detailed parameters

Maximum number of units on CEX bus: 12

Connector: RJ-45 female head (8-pin)

24V power consumption (typical value): 150 mA

Environment and Certification

Working temperature:+5 to+55 ° C (+41 to+131 ° F)

Storage temperature: -40 to+70 ° C (-40 to+158 ° F)

Corrosion protection: Complies with the G3 standard of ISA 71.04

Protection level: IP20 compliant with EN60529 and IEC 529

Size and weight

Width: 59 mm (2.3 in.)

Height: 185 mm (7.3 in.)

Depth: 127.5 mm (5.0 in.)

Weight (including base): 700 g (1.5 lbs)
