Honeywell FS10 Fire Detection Systems For Liquid Paint Spray and Electrostatic Powder Coating

FS10-R General Specification

Sensitivity: For a 0.3 square meter (1 square foot) fire, the factory sets it to 13.7 meters (45 feet) and 9.1 meters (30 feet) * (note: detectors set to 13.7 meters (45 feet) sensitivity have no warning/fire early warning output).

Response time: 0.3 seconds for warning (for "fireball" type fires), 1 second for early fire warning, and less than 5 seconds for fire alarm (if the fire persists).

Field of view: 90 ° (horizontal and vertical ± 45 °).

Input power supply: nominal 24VDC (18-32VDC) - regulated.

Power consumption: Normal 85mAh (typical value), alarm 120mAh (typical value).

Output relay: SPST for warning/early warning, normally open; The fire alarm is SPST, normally open; The fault is SPST, constantly open without power supply, with a rated contact value of 1 ampere at 24VDC.

Normal operation: The faulty relay is powered on and not locked; All other relays are powered off; Fire and warning relays can be selected to be locked or non locked.

Working temperature: -40 º C to+85 º C (-40 º F to+185 º F).

Humidity range: 0% to 90% relative humidity, no condensation.

FS10 Card Controller Specification

Shell: NEMA 1 steel shell.

Indicator: 4 status LEDs, corresponding to normal operation, warning, fire early warning (FEW), fire alarm, and fault status.

Input power supply: 24V DC (+10/-15%).

Power consumption: 65 milliamps, nominal 1.6 watts.

Output signal relay: There are multiple models, and different models have different relay configurations.

FirePic ™： There are a total of 6, each lasting 8 seconds.
