MOOG D136-001-001 MOTION CONTROLLER

MOOG D136-001-001 MOTION CONTROLLER

Moog Motion Control

Moog offers a variety of freely programmable Motion Controllers, each of them designed with specialized functionality to meet a range of customer requirements. Regardless of your application, we have a Motion Controller that will meet your requirements.

MSC III Motion Controller

The MSC III Motion Controller is a high performance Motion Controller with PLC functionality that is ideal for complex centralized and decentralized applications. The MSC III Motion Controller offers several fieldbus interfaces, high resolution analog inputs/outputs, position sensor interfaces and digital inputs/outputs. It is designed for fast and accurate closed-loop control of multiple hydraulic and electric actuators.

MASS (Moog Application Software Suite)

The IEC 61131-3 is an integrated development environment based on CODESYS 3. MASS offers full programming, debugging, simulation, parameterization, visualization and tracing capabilities. It helps you to achieve enhanced machine performance via special Moog libraries of pre-programmed function blocks, and enables users to solve advanced control problems. The MASS is designed to improve machine control by providing powerful, advanced capabilities for closed-loop and open-loop control, as well as PLC functionality.

Feature

·Short cycle times

·Easy-to-use software and flexible hardware

·Support of user-defined open control structures

·Special Moog libraries of pre-programmed function blocks

·Multiple connectivity options

·Remote servicing and debugging

Benefit

·Higher machine productivity

·Fast start-up commissioning

·Maximum flexibility

·Solve advanced control problems quickly

·Quick integration

·Convenience

Environmental data

Operating temperature range：+5 to +55 °C (+41 to +131 °F)

Maximum mean temperature in operation for 24 hours：+50 °C (+122 °F)

Storage temperature range (in original packaging)：-25 to +70 °C (-13 to +158 °F)

Relative air humidity：10 to 95% (non condensing)

Maximum operation height：2,000 m (6,500 ft)

Maximum storage height：3,000 m (9,800 ft)

Air pressure for transportation：≥ 70 kPa (corresponds to an elevation of ≤ 3,000 m (9,800 ft))
