ABB 3BHB003689 Multifunction Controller Module

Energy and Power: In the boiler control system of thermal power plants, the module monitors the boiler's water level, steam pressure, temperature and other key parameters, and controls the operation of feed pumps, fans, safety valves and other equipment. Through real-time data analysis and control strategy adjustment, it achieves efficient combustion and stable operation of the boiler, improves power generation efficiency, and reduces energy consumption; at the same time, it integrates with the DCS system of the power plant to achieve centralised monitoring and management of the entire power generation process.

Robot control scenarios

Industrial Robot: In the welding robot workstation, 3BHB003689 acts as the core control module, receives welding task commands from the host computer, and calculates and controls the motion trajectory of each joint of the robot, welding speed, welding current and other parameters according to the requirements of the welding process and the kinematic model of the robot. By cooperating with vision sensors, it can achieve accurate positioning of the welding position and seam tracking to ensure the consistency and stability of the welding quality, which is widely used in welding operations in automobile manufacturing, machining and other industries.

Collaborative robots: In electronic assembly workshops, collaborative robots use 3BHB003689 to achieve safe collaboration with workers. The module controls the robot's movement speed and strength, and automatically reduces the speed or stops the movement when it detects that the distance to the worker is too close to ensure personnel safety; at the same time, according to the requirements of the product assembly process, it accurately controls the robot to complete the operations of grasping, placing, and assembling the electronic components, so as to improve the assembly accuracy and production efficiency.
