GE A-S1300B Mark* VIe Control

Advantages of technical standards

Strict safety standards: Following EN 61010 - 1, CAN/CSA 22.2 No. 61010 - 1 - 12, UL 61010 - 1 and other safety standards,

the safety requirements of electrical equipment in measurement, control and laboratory use are comprehensively regulated.

From electrical safety, mechanical safety to protection level and other aspects to provide protection,

such as to meet the IP20 (NEMA 1) intrusion protection requirements, effectively preventing personnel from electric shock and intrusion of foreign objects,

reduce the safety risk, to ensure the safety of operators and equipment.


Strong EMC performance: Complies with Directive 2004/108/EC and other EMC directives, as well as EN 55011, IEC 61000 series and other relevant standards.

It has excellent performance in a number of EMC indicators such as radiated and conducted emissions, ESD immunity, RF radiation immunity, etc.

It can effectively resist external electromagnetic interference, ensure stable operation of the system in complex electromagnetic environments,

and avoid equipment malfunctions or data errors caused by electromagnetic interference.


Suitable for hazardous areas: In terms of hazardous area applications, it meets ATEX Class I, Division 2, Groups A, B, C, D

T4 standards and is suitable for a variety of hazardous environments.

This allows the product to be used safely in places where flammable and explosive gases, dusts and other hazardous substances are present,

broadening the product's range of applications and guaranteeing production safety in special industrial environments.


High level of functional safety: Mark VIeS safety controllers comply with functional safety standards such as IEC 61508:2010 Parts 1 - 7 and EN50402:

2005 + A1:2008, and are SC 3 (SIL 3 Capable) system capable.

This means that the controller can reliably perform safety functions in safety-critical applications, effectively reducing risks and safeguarding people,

equipment and the environment.


Quality control norms: Product design, manufacturing, supply and service follow the ISO 9001:2008 quality management system standards,

from raw material procurement, production process control to after-sales service, there are strict quality control processes.

It ensures stable and reliable product quality, reduces product defects, improves user satisfaction and enhances product competitiveness in the market.


technical specification

Hardware Specifications

Controller: Single board design with integrated main processor, multiple Ethernet drivers, USB and COM ports.

The processor is available in different models, e.g. 600MHz for UCSBH1A and 1200MHz for UCSBH3A, and supports multiple redundancy configurations,

18 - 32V dc operation, and no battery. Operating temperature range varies between models, e.g. -30 to 65°C for UCSBH1A,

0 to 65°C for UCSBH3A, humidity range 5 to 95% non-condensing.


I/O Modules: Consists of terminal boards, terminal blocks, and I/O packages in T-type and S-type models; T-type modules have removable

24-point barrier terminal blocks; S-type modules are small and have fixed or removable terminal blocks; the I/O consists of a variety of components,

with dual 100MB Ethernet ports, in-circuit repair, and auto-reconfiguration; and is powered by a 28V dc power supply with overcurrent protection.


Network Equipment: IONet is 100MB Ethernet, supports non-redundant, dual redundant, and triple redundant configurations,

and follows IEEE 802.3u standards. Cable types include UTP Cat 5e and optical fibre,

with maximum segment lengths of 100m (copper) and 2km (optical fibre) respectively, and support for RJ-45 and SC (optical fibre) interfaces.

The industrial grade switches are used for IONet, support redundant power supplies, and operate at temperatures from -40 to 85°C.


Software Specifications

Operating system: Controller and I/O modules use a real-time multitasking operating system such as QNX.

Control Software: Written in a configurable control block language similar to the IEEE 854 32-bit floating-point format,

supports Sequential Function Charts (SFC) programming, and is stored in non-volatile memory.

Software Suite: The ControlST software suite includes tools such as WorkstationST for alarm management, historical data storage, etc.

and ToolboxST for hardware and software configuration, diagnostics, graphical editing, trending, and more.
