STOBER POSIDRIVE ® How to install MDS 5000?

Software usage restrictions: Customers are not allowed to use, copy, modify, transmit/transfer the software beyond the scope of the license, and are not allowed to perform reverse assembly, reverse compilation, or other conversion operations on the software. They are also not allowed to sublicense, rent, or lease the software.

Product maintenance scope: STOBER only assumes maintenance obligations for the last two current program versions prepared and released for use, and may choose to correct program errors or provide new versions; If the error cannot be corrected immediately, a temporary solution will be provided (which may require users to comply with special operating procedures); The right to correct errors can only be claimed when the reported errors are reproducible or can be recorded through machine output, and are reported in reproducible form and provide useful information for error correction; STOBER does not assume the obligation to correct errors in programs modified or tampered with by customers, unless the customer can prove that the error is not related to tampering; STOBER needs to store the current valid program version in a special protected location (fireproof data safe, bank vault).

Technical parameters

（1） Model Interpretation

Taking "MDS 5075/L" as an example, "MDS" is the product series, "5" represents the fifth generation, "075" represents a power of 7.5kW, "/L" represents the auxiliary voltage of the control electronic device as external 24V ("/H" represents the auxiliary voltage as DC link).

（2） General electrical parameters

Parameter Value

Under the rated maximum ambient air temperature data of 0-45 ° C, it can reach 55 ° C when the power is reduced by 2.5%/° C

Relative humidity during operation is 85%, with no condensation

Installation altitude below 1000m without restrictions, power reduction of 1.5%/100m from 1000-2000m

High voltage category complies with Class III of EN 61800-5-1

Pollution level meets level 2 of EN 60204/EN 50178

Protection level IP 20

The installation position is usually vertical installation

Ventilation method with built-in fan

Maximum voltage limit 830V

Brake chopper disabled voltage 740V/760V

（3） Detailed parameters of each specification and model

1. Specification 0/BG0

Equipment model MDS 5007 (ID: 44556) MDS 5004 (under preparation, ID：44555） MDS 5008（ID：44557） MDS 5015（ID：44558）

Recommended motor power 0.75kW 0.37kW 0.75kW 1.5kW

Connection voltage 1 × 230V (L1-N),+20%/-40%, 50/60Hz 3 × 400V (L1-L3),+32%/-50%, 50Hz; 3 × 480V (L1-L3),+10%/-58%, 60Hz Same as MDS 5004 Same as MDS 5004

Power fuse 1 × 10AT 3 × 6AT 3 × 6AT 3 × 10AT

Servo motor operation (servo control mode) - rated current (IN) 3 × 3.0A 3 × 1.0A 3 × 1.5A 3 × 3.0A

Servo motor operation (servo control mode) - maximum overload of 250%/2 seconds, 200%/5 seconds same as left, same as left

Servo Motor Operation (Servo Control Mode) - Clock Pulse Frequency 8kHz Same Left Same Left Same Left

Three phase current motor operation (V/f, VC, SLVC control mode) - rated current (IN) 3 × 4.0A 3 × 1.3A 3 × 2.1A 3 × 4.0A

Three phase current motor operation (V/f, VC, SLVC control mode) - maximum overload of 180%/5 seconds, 150%/30 seconds same as left, same as left, same as left

Three phase current motor operation (V/f, VC, SLVC control mode) - clock pulse frequency 4kHz (adjustable to 16kHz during derating) same as left, same as left, same as left

Braking resistor (accessories, see Chapter 7.2) 100 Ω: maximum 1.6kW, same as left 200 Ω: maximum 3.2kW, same as left

The allowed length of shielded motor cable is 50m, and the rating for 50-100m needs to be reduced (see Chapter 7.2.44). Same as left, same as left

When Ia=IN, the power consumption is 80W, 50W, 65W, and 90W

When Ia=0A, the maximum power consumption is 30W (depending on the connected option board and sensor, such as encoder), same as left, same as left

The maximum cross-sectional area of the wire is 2.5mm ², same left, same left, same left

Dimensions (H × B × T) [mm] 300 × 70 × 175 (193) (including depth of braking resistor RB 5000) Same as left, same as left

Weight [kg] (Unpackaged/Packaged) 2.2/3.2 Same Left Same Left Same Left

Maximum voltage limit 440V 830V Same Left Same Left

Brake chopper opening level 400V/420V 780V/800V same left same left

Brake chopper disable voltage 360V/380V 740V/760V same left same left

2. Specification 1/BG1

Parameter Value

Connection voltage 3 × 400V (L1-L3),+32%/-50%, 50Hz; 3×480V（L1-L3），+10%/-58%，60Hz

Power fuse 3 × 20AT

Servo motor operation (servo control mode) - rated current (IN) 3 × 10A

Servo motor operation (servo control mode) - maximum overload of 250%/2 seconds, 200%/5 seconds

Servo motor operation (servo control mode) - clock pulse frequency 8kHz

Three phase current motor operation (V/f, VC, SLVC control mode) - clock pulse frequency 4kHz (adjustable to 16kHz during derating)

Braking resistor (accessory) Ω: maximum 6.4kW

Power consumption (IN) 170W, 200W

Power consumption (Ia=0A) up to 30W (depending on the connected option board and sensor, such as encoder)

The maximum cross-sectional area of the wire is 4mm ²

Maximum voltage limit 830V
