Core parameters and product configuration

1. Key specifications

Pressure parameters: maximum pressure 2500 PSI, rated pressure 2000 PSI.

Flow parameters: maximum water flow rate of 1.76 US GPM (6.66 LPM), rated water flow rate of 1.2 US GPM (4.54 LPM).

Power parameters: Input 120V AC, 60Hz, 13A, equipped with Class A GFCI leakage protection plug, double insulation design.

Applicable water source: Only cold water (tap water) is supported, and the use of hot water, lake water, pool water, etc. is prohibited. The water source pressure should not exceed 150 PSI.

2. Core configuration

Cleaning accessories: 0 ° turbine nozzle (high-pressure cleaning), 15 °/25 ° nozzle (medium pressure cleaning), soap nozzle (low-pressure spraying).

Body components: high-pressure hose, spray gun, extension rod, soap box, roller (easy to move), cable storage rack, hose storage rack.

Safety configuration: trigger safety lock (to prevent accidental contact), GFCI leakage protection (to be tested monthly), 20A circuit breaker (overload protection).

Core functions and usage scenarios

1. Core functions

Multi scenario cleaning: By changing the nozzle to meet different needs, high-pressure nozzles can remove stubborn stains and paint peeling, medium pressure nozzles are suitable for brick and stone roads, and soap nozzles can be used with specialized cleaning agents to clean vehicles, doors, and windows.

Automatic start stop: When the trigger is triggered, the machine starts and automatically stops when released, reducing energy consumption and wear.

Convenient operation: The roller design is easy to move, components can be quickly assembled and disassembled, and cables and hoses have dedicated storage structures.

2. Applicable and taboo scenarios

Applicable for cleaning hard surfaces such as vehicles, decks, sidewalks, fences, and exterior walls of buildings.

Taboo: Do not directly spray personnel, animals, electrical equipment, glass (easily broken); Do not use in damp environments, flammable dust/liquid areas; Not suitable for cleaning medical equipment or precision instruments.

Complete operation process (assembly → use → shutdown → maintenance)

1. Assembly steps (completed within 10 minutes)

Install the roller: Tilt the body, align the roller with the bottom slot, and push it in firmly until you hear a "click" sound, ensuring that the roller is securely installed (you can gently shake it for testing).

Fixed storage components: Align the spray gun storage rack, hose storage rack, and cable storage rack with the reserved card slot on the body, slide them into place, and tighten the fixing screws (if any).

Connect high-pressure hose:

Take out the high-pressure hose, align one end with the water outlet of the machine body, press the hose buckle and push it in, and tighten the locking ring clockwise.

Align the other end with the spray gun interface, press the buckle and tighten it, gently pull the hose to confirm a secure connection.

Connect water source:

Check if the filter inside the water inlet of the aircraft is intact and unobstructed (if there are impurities, rinse with clean water).

Connect one end of the garden hose to the faucet and the other end to the water inlet of the machine. Tighten the buckle clockwise and turn on the faucet to test for water leakage.

Assemble spray gun and nozzle:

Insert the extension rod into the spray gun interface, tighten clockwise (do not apply excessive force to avoid damaging the thread), and gently pull to confirm fixation.

Select the desired nozzle, align it with the front end interface of the extension rod and press it. Once you hear the snap sound, it will be installed in place; Press the buckle and pull out the nozzle during disassembly.

2. Usage steps (divided into regular cleaning and cleaning with cleaning agents)

(1) Regular cleaning (without cleaning agents)

Preparation before startup:

Turn on the faucet to ensure smooth water flow and no impurities.

Unlock the safety lock of the spray gun trigger, press the trigger to release the air and residual impurities in the pipeline until there are no bubbles in the continuous water flow, and then lock the safety lock.

Insert the power plug into the grounding socket and ensure that the plug is dry.

Startup and Cleaning:

Press the "start stop button" on the machine body, and the machine will automatically stop after running for 1-2 seconds (the automatic start stop function is normal).

Unlock the trigger safety lock, press the trigger, the machine starts and sprays high-pressure water flow to start cleaning.

Cleaning technique: Starting from the bottom of the surface, clean upwards in a left-right translation to avoid water flow from top to bottom (which may leave water marks); For stubborn stains, the distance between the nozzle and the surface can be shortened (but not less than 15cm), or the 0 ° turbine nozzle can be replaced.

Shutdown operation:

Release the trigger, the machine will automatically stop, and lock the trigger safety lock.

Turn off the faucet and press the trigger to release any residual pressure in the system.

Disconnect the power supply, wrap the cable around the storage rack, wrap the high-pressure hose around the hose storage rack, and place the spray gun into the storage rack.
