Honeywell 05701-A-0285 Analog Output Module

Honeywell 05701-A-0285 Analog Output Module

Functional Features

Multi channel analog output: This module is a 4-channel analog output module that can process and output 4 analog signals simultaneously, meeting the synchronous control requirements of multiple devices or parameters in various industrial control scenarios.

Flexible output modes: Supports two output modes of 0-20mA or 4-20mA, which can be easily reconfigured through computer connection to engineering ports according to actual application scenarios and device requirements, making it convenient to match with different types of sensors, actuators, and other devices.

Isolation current loop output: Provides isolation current loop output that can follow the sensor signal level, effectively isolate external interference, ensure the stability and accuracy of the output signal, improve the system's anti-interference ability, and is suitable for industrial applications in complex electromagnetic environments.

Passive current control: The module can operate at a circuit voltage of up to 40V. Through passive current control components, the output current can be stably controlled to ensure the reliability of analog output, even in the case of large voltage fluctuations.

Technical Parameter

Power requirements: The nominal input voltage is 24Vdc, which can operate stably within a certain voltage fluctuation range and provide reliable power support for the normal operation of the module.

Working temperature range: The working temperature is -20 ° C to+50 ° C, which can adapt to certain high and low temperature environments and meet the temperature conditions of most industrial sites.

Humidity range: The humidity range is 0% -95% without condensation, which can maintain good performance in high humidity environments and avoid electrical failures caused by humidity.

Size: The module size is 12.7cm x 5.1cm x 12.7cm, with a compact size that is easy to install and integrate into various industrial control systems, saving space inside the control cabinet.

Application area

Industrial automation control: On industrial production lines, it can be used to control the speed of motors, the opening of valves, etc., to achieve precise control of the production process, improve production efficiency and product quality. For example, in chemical production, controlling the opening of the reactor feed valve, accurately adjusting the material flow rate, and ensuring the stable progress of chemical reactions.

Process monitoring and data acquisition: Used in conjunction with sensors, the analog signals collected by sensors are processed and output, and transmitted to the upper computer or data acquisition system for monitoring and analysis. In the petrochemical industry, collecting and outputting simulated signals such as temperature, pressure, and flow rate helps operators understand the real-time operation status of the production process.

Building automation system: used to control the temperature adjustment of air conditioning systems, brightness adjustment of lighting systems, etc., to achieve intelligent management of buildings and achieve the goals of energy conservation and comfort. For example, automatically adjust the cooling and heating power of the air conditioner and the brightness of the lighting fixtures based on indoor and outdoor temperature and light intensity.
