GE DS3800HAFA ANALOG AMP CARD

GE DS3800HAFA ANALOG AMP CARD

Part Number DS3800HAFA Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark VI/VIe Function Module Availability In StockDS3800HAFA is a custom address card developed by GE. The GE Turbine Control Board DS3800HAFA has 11 jumpers for board configuration and a single 20-pin connector. The GE Turbine Control Board is designed with features that make installation and removal of the board simple.

The board is put into the interior of the drive's board rack. The bottom of the board's modular connectors automatically lines with the drive's connectors, forming a secure connection. On the top of the board are retention levers that secure the board in the rack. After the board is placed, you can connect a 20-pin ribbon cable to one of the 20-pin connectors on the top edge of the board. When you're ready to remove the board, unplug the 20-pin ribbon wire and move it out of the way.

When the ribbon cable is linked to the board, avoid tugging on it. This can damage the connector and cause the wires to be disconnected from the connector on the ribbon cable's end. The 11 jumpers are useful for customizing the board to meet your needs. Each of the jumpers has a unique identification number. RST1, RST2, FRZ1, and WRD3 are some of the jumper IDs. Use the same jumper settings on the replacement board as you did on the old board when replacing it.

Compatibility

ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave

ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module
