    GE DS3800HACB Regulator Board

    • ¥22500.00
      ¥24520.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:3.600KG
    • Quantity:
    • (Inventory: 33)
Description

GE DS3800HACB Regulator Board


GE DS3800HACB Regulator Board

Part Number DS3800HACB Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark VI/VIe Function Module Availability In StockDS3800HACB is a custom address card developed by GE. The GE Turbine Control Board DS3800HACB has 11 jumpers for board configuration and a single 20-pin connector. The GE Turbine Control Board is designed with features that make installation and removal of the board simple.

The board is put into the interior of the drive's board rack. The bottom of the board's modular connectors automatically lines with the drive's connectors, forming a secure connection. On the top of the board are retention levers that secure the board in the rack. After the board is placed, you can connect a 20-pin ribbon cable to one of the 20-pin connectors on the top edge of the board. When you're ready to remove the board, unplug the 20-pin ribbon wire and move it out of the way.

When the ribbon cable is linked to the board, avoid tugging on it. This can damage the connector and cause the wires to be disconnected from the connector on the ribbon cable's end. The 11 jumpers are useful for customizing the board to meet your needs. Each of the jumpers has a unique identification number. RST1, RST2, FRZ1, and WRD3 are some of the jumper IDs. Use the same jumper settings on the replacement board as you did on the old board when replacing it.

Features

▪ Contains 10 Mbytes of battery-backed user memory and 10 Mbytes of non-volatile flash user  memory.

▪ Provides access to bulk memory via reference table %W.

▪ Configurable data and program memory.

▪ Programming in Ladder Diagram, C, Structured Text, and Function Block Diagram.

▪ Supports auto-located Symbolic Variables that can use any amount of user memory.

▪ Reference table sizes include 32Kbits for discrete %I and %Q and up to 32K words each for  analog %AI and %AQ.

▪ Supports Series 90-70 discrete and analog I/O, communications, and other modules. For a  list of modules supported, refer to the PACSystems RX7i Installation Manual, GFK-2223.

▪ Supports all VME modules supported by Series 90-70.

▪ Supports RX7i data monitoring over the web. Allows a combined total of up to 16 web server  and FTP connections.

▪ Supports up to 512 program blocks. Maximum size for a block is 128KB.

▪ Test Edit mode allows you to easily test modifications to a running program.

▪ Bit-in-word referencing.

▪ Battery-backed calendar clock.

▪ In-system upgradeable firmware.

▪ Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232  Ethernet station manager serial port.

▪ The embedded Ethernet interface provides:

- Data exchange using Ethernet Global Data (EGD)

- TCP/IP communication services using SRTP

- Support for SRTP Channels, Modbus/TCP Server, and Modbus/TCP Client

- Full programming and configuration services

- Comprehensive station management and diagnostic tools

- Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network  switch providing auto-negotiated network speed, duplex mode, and crossover detection.

- User-configurable Redundant IP address

- Time synchronization to SNTP time server on Ethernet network (when used with  Release 5.00 or later CPU module).

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
