ABB 3BUS092084R0001 IndustrialIT System 800xA
DESCRIPTION
Symphony Harmony is a proven process control system for demanding applications in various industries. The wide range of Harmony references include the power generation, chemical, pharmaceutical, pulp and paper, water and wastewater, petrochemical, metal and mining, food and beverage, cement, and sugar industries. The addition of System 800xA functionality provides Harmony users with the technology and solutions needed to achieve a sustainable competitive advantage in their industries.
Features and Benefits
■ Extending the Return-on-Investment of Harmony Systems.New hardware and software product releases increase operating efficiency and extend the life of installed systems. New products and programs make the decision to evolve existing systems straightfor ward and easy.
■ System 800xA Extends Harmony System Functionality to Achieve Greater Productivity Gains.System 800xA extends the reach of traditional automation systems. When integrated with Harmony systems, productivity gains necessary to succeed in todayís business world are achieved. System extensions include:
·I/O Capability. Significantly reduce field wiring costs with S800 I/O. Modular design allows I/O installation in close proximity to sensors, actuators, and field devices. ·Asset Optimization. Optimize plant asset availability and performance. Significantly increase process uptime and reduce maintenance costs through optimized remediation work processes and early detection of asset performance problems.
·Information Management. Improving visibility of integrated information results in effective decision making. Information Management provides pertinent information required to perform efficient planning, analysis, and actions.
·Personalized User Workplaces. Reduced time to decision and action is achieved with Process Portal personalized workplaces. Information and workplace layouts are optimized to maintenance, engineering, management, and operating personnel preferences and needs.
Extending the Return-on-Investment of Harmony Systems
ABBís pledge of Evolution through Enhancement (Figure 1) ensures that future advances in system technologies will extend the life cycle and the return-on-investment of the installed Harmony system. Other vendors may talk about investment protection, but ABBís proven programs are truly unique in the industry. All told, from the introduction of Network 90Æ in 1980, through each of the evolutionary steps of INFI 90Æ, INFI 90 OPEN, and Symphony Harmony, this family of systems represents the largest contiguous installed base of any process automation system in the world.
ABB continues to add traditional DCS functionality for the Harmony system. This focus has resulted in many new functions and technology updates for Harmony products including Rack I/O modules, Bridge Controllers, communication modules, Composer system configuration tools, and operator consoles. The following sections summarize the most recent enhancements to the Harmony system.
Harmony Control, I/O, and Communications
The Harmony Rack modules (Figure 2) have been redesigned with modern board components and surface mount technology. These redesigned modules are form, fit, and functional equivalents to the Network 90, INFI 90, and INFI 90 OPEN modules providing backward compatibility to ensure a long life cycle for Harmony systems.
The systemís flagship controllers, the Harmony Bridge Controller family, have remained state-of-the-art through annual software and hardware enhancement releases. Following ABBís commitment to Evolution through Enhancement, the Harmony Bridge Controllers preserve existing system control logic configuration, thereby providing predictable and risk free evolution for the systemís control execution environment. The Harmony Bridge Controller family supports all existing function code execution, custom user programs, and foreign device interfaces.
New communication modules have been released (INNPM12/INNIS11) that support both the Plantloop and INFI-NET communication standards. This offering allows system users to incrementally upgrade from Plantloop to INFI-NET one process control unit at a time. Also released, are INFI-NET-to-INFI-NET Remote Gateway modules. All of these communication modules are form, fit, and functional replacements for their earlier versions.
System 800xA Asset Optimization highlights include:
■ Complete Asset Optimization: Provides a higher return on all plant assets through optimized remediation work processes and early detection of failure via its single environment for engineering, operations, and notification.
■ Automatic Monitoring of Maintenance Conditions and Automatic Alarms: Real-time monitoring of asset Key Performance Indicators (KPI) facilitates fast, reliable implementation of corrective actions.
